Westerschelde 06 August 2018 |
|
Name |
HIGH CURRENT |
|
Type |
Oil product tanker |
|
IMO-number |
9400801 |
|
Call sign |
3FAQ2 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
28.321 t registered |
|
DWT |
Summer: 46.590 t |
|
NT |
12.822 t registered |
|
Length |
179,90 m overall |
|
Breadth |
32,20 m extreme |
|
Draught |
Max: 12,80 m |
|
Moulded L x B x D |
172,00 x 32,20 x 19,25 m |
|
Registered L x B x D |
172,68 x 32,20 x 19,25 m |
|
Freeboard |
6.480 mm |
|
Depth |
19,25 m moulded |
|
Speed |
Max: 15,7 knots |
|
Built |
2009 |
|
Keel laid |
09/07/2008 |
|
Launch date |
26/11/2008 |
|
Date of completion |
28/04/2009 |
|
Builder |
Naikai Zosen Corporation Setoda Shipyard |
|
Yard number |
720 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W-Hitachi 6S50MC-C - 2 stroke single acting 6 cylinder 500 x 2.000 mm combustion engine 9.480 kW at 127,0 rpm Manufacturer: Hitachi Zosen Corp. Ariake Machinery Works |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 480 mm |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Auxiliary vertical boiler - 9,0 bar Evaporation : 16,10 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
4x Generators total 3.289 kVA |
|
Cargo tank capacity |
Liquid: 55.029 m³ |
|
Tank capacities |
Fuel oil: 2.409 m³ Fresh water: 307 m³ |
|
Manager |
Ishima Pte. Ltd. |
|
Registered owner |
Botan Ship Holding SA |
|
Latest data adjustment |
01 January 2019 |
