Med Antarctic 01

Westerschelde 21 August 2018



Name

MED ANTARCTIC

Previous names

Build as: Eregli 30

Type

Oil/Chemical tanker

IMO-number

9462316

Call sign

9HA4607

Flag

Malta

Port of registry

Valletta

GT

5.651 t

DWT

Summer: 8.269,88 t

NT

2.602 t

Length

123,90 m overall

116,26 m between perpendiculars

Breadth

17,20 m extreme

Draught

Summer: 7,24 m

Ballast: 4,83 m

Height from keel to mast

36,62 m

Air draft

30,96 m

29,38 m loaded condition

Freeboard

1.977 mm

Depth

9,20 m moulded

Speed

14,0 knots

Built

2017

Builder

Eregli Gemi Insa Sanayi Shipyard
Zonguldak
Turkey

Yard number

30

Hull material

Steel

Hull type

Double hull

Watertight compartments

8

Continuous decks

1

Main engine

1x MaK 8M32C - 4 stroke 8 cylinder combustion engine 4.000 kW / 5.435 hp at 600 rpm

Builder: Caterpillar Motoren Gmbh & Co. Kg

Propellers

1x Screw propeller controllable pitch

Boilers

2x CHO 64,00 m² / 10,0 bar
1x CHR 48,00 m² / 10,0 bar

Shaft generator

1x 1.499 kVA - 1.199 kW

Generators

3x MAN D2876 LE 301 main diesel generatorsets each 731 kVA - 585 kW - 842 hp at 1.800 rpm

Emergency generator

1x Diesel generatorset 188 kVA - 150 kW - 296 hp

Bow thruster

1x 576,65 bhp

Number of cargo tanks

12

Total cap. of tanks 98%

8.919 m³

Number of slop tanks

2

Slop tank capacity 98%

184 m³

Number of segregations

14 Double valves

Pumps

12x Framo cargo pumps each 250 m³/h

2x Framo cargo pumps 100 m³/h

2x Ballast pumps each 500 m³/h

Manifolds

Distance from bow to centre manifold: 61,61 m

Distance from stern to centre manifold: 54,71 m

Distance between manifolds: 750 mm

Distance from ship side to manifold: 2.650 mm

Tank capacities

Fuel: 343,59 m³

Ballast: 3.824 m³

Anchor equipment

1x Crane - SWL 5,0 t

Manager

Bridge Tankers Ltd.

Operator

YMN Tanker Marine Management INC.

Altunizade Mah. Ord. Prof. Fahrettin Kerim Gökay Cad. Denizciler İş Merkezi, A Blok No:18/1

34662 Üsküdar

Istanbul

Turkey

Registered owner

Sea Tankers 7 Ltd.

Latest data adjustment

07 December 2018
