Baltic Favour 02

Vlissingen 04 December 2017



Baltic Favour 01
04/12/17



Name

BALTIC FAVOUR

Type

Tanker for oil and chemicals

IMO-number

9327372

Call sign

9HA3692

Flag

Malta

Port of registry

Valletta

Previous flags

2006 - 2016 Cyprus, Limassol - Call sign: C4FV2

GT

23.337 t registered

Suez: 24.08,67 t

DWT

Summer: 37.105 t

Winter: 36.033 t

NT

10.107 t registered

Suez: 20.817,19 t

Panama; 23.240 t

Displacement

Summer: 46.003 t

Winter: 44.931 t

Length

182,55 m overall

176,08 m between perpendiculars

Breadth

27,34 m extreme

Draft

Summer: 11,22 m

Winter: 10,98 m

Keel to masthead

45,81 m

Air draft

Lightship: 43,31

Normal ballast: 37,75 m

At loaded summer deadweight: 34,59 m

Freeboard

Summer: 5.514 mm

Winter: 5.750 mm

Depth

16,70 m moulded

Speed

Ballast: 15,0 knots

Laden: 14,5 knots

Built

2006

Keel laid

24/10/2005

Launch date

03/01/2006

Date of completion

24/02/2006

Builder

Hyundai Mipo Dockyard Co., Ltd.
South Korea

Yard number

438

Hull material

Ordinary strength steel

High strength steel

Hull type

Double hull

Movable bulkheads

Transverse: 9
Longitudinal: 3

Continuous decks

1

Main engine

1x MAN -B&W/7S50MC-C MK7- 7 cylinder 500 x 2.000 mm combustion engine 11.060 kW at 127,0 rpm

Manufacturer: Bryansk Engine Works

Propellers

1x Fixed controllable pitch propeller

Boilers

1x Auxiliary boiler vertical shell type, oil/gas fired Mission OL - 8,8 bar

Manufacturer: Aalborg Industries A/S

1x Auxiliary boiler, exhaust gas water tube

Manufacturer: KangRim Industries. Co., Ltd.

Generators

3x Hyunday Hinsen 6H2132 main diesel generatorsets each 850 kW

Emergency generator

1x Cummins L-10 diesel generatorset

Bow thruster

1x Kawasaki 900 kW / 1.224 bhp

Number of cargo tanks

12

Cargo tank capacity 98%

Seg#1: 6.035,6 m³ (1 port & stbd)
Seg#2: 7.176,2 m³ (2 port & stbd)
Seg#3: 7.194,6 m³ (3 port & stbd)
Seg#4: 7.194,6 m³ (4 port & stbd)
Seg#5: 7.194,6 m³ (5 port & stbd)
Seg#6: 6.341,8 m³ (6 port & stbd)

Total: 41.137,4 m³

Number of slop tanks

2

Slop tank capacity 98%

878,6 m³

Pumps

10x Centrifugal cargo pumps each 500 m³/h

2x Centrifugal cargo pumps each 320 m³/h

10x Centrifugal cargo pumps each 150 m³/h

2x Centrifugal deelwell pumps each 750 m³/h

Manifolds

Bow to centre manifold: 92,30 m

Stern to centre manifold: 90,25 m

Distance bridge front to centre of manifold: 56,65 m

Distance between cargo manifold centres: 2.000 mm

Distance ships rail to manifold: 4.400 mm

Distance manifold to ships side: 4.600 m

Top of rail to centre of manifold: 850 mm

Distance main deck to centre of manifold: 2.100 mm

Spill tank grating to centre of manifold: 900 mm

Number of tanks

Ballast: 15

Lubricating oil: 7

Fresh Water: 7

Diesel oil: 5

Fuel oil: 4

Waste water: 2

Chain: 2

Hydraulic oil: 1

Slop: 1

Sludge: 1

Tank capacities 100%

Diesel oil: 207 m³ / 177,47 t

Freshwater: 513,5 m³

Fuel oil: 678,5 m³/ 669,48 t

Hydraulic oil: 15,7 m³ / 14,13 t

Lube oil: 101,6 m³ / 91,44 t

Tank Ballast: 18.873,8 m³ / 19.345,64 t

Anchor equipment

Length: 605,10 m

Diameter: 66 mm

Lifting equipment

1x Engine room crane - SWL 2,0 t

1x Hose handling crane - SWL 10,0 t

1x Provision & rescue boat crane - SWL 10,0 t

1x Provision Crane - SWL 2,0 t

Crew size

30

Technical manager

Interorient Marine Services (Germany) GmbH & Co. KG
Kajen 12
20459 Hamburg
Germany

Commercial manager

Norient Product Pool ApS
52, Strandvejen
DK-2900 Hellerup
Denmark

Registered owner

Baltic Favour Shipping Company Limited
171 Old Bakery Street
Valletta 1455
Malta

Latest data adjustment

27 April 2018
