Westerschelde 08 October 2019 |
 |
 |
|
| Westerschelde 085/10/19 | Westerschelde 22/11/17 | |
|
Name |
TERN OCEAN |
|
Type |
Tanker for chemicals & Oil products |
|
Main products |
Chemicals |
|
IMO-number |
9747986 |
|
Call sign |
OYBJ2 |
|
Flag |
Denmark |
|
Port of registry |
Skagen |
|
GT |
11.374 t |
|
DWT |
14.827 t |
|
NT |
4.780 t |
|
Length |
147,00 m overall 143,50 m between perpendiculars |
|
Breadth |
22,00 m moulded |
|
Draught |
9,00 m |
|
Freeboard |
2.711 mm |
|
Depth |
11,70 m moulded |
|
Speed |
14,5 knots |
|
Built |
2017 |
|
Keel laid |
08/12/2015 |
|
Date of completion |
15/03/2017 |
|
Builder |
AVIC Dingheng Shipbuilding Co., Ltd. Yangzhou China |
|
Yard number |
AD0058 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 5RT-flex 50 DF - 2 stroke single acting 5 cylinder 500 x 2050 mm combustion engine 5.850 kW / 7.954 hp at 102,0 rpm LNG dual-fuel engine Built: 21/07/2016 Builder: Yuchai Marine Power Co., Ltd., FuShan Industrial Park,DouMen District Zhuhai - China |
|
Propellers |
1x Screw Propeller Controllable pitch - aft at 102,0 rpm |
|
Boilers |
1x CHR Gesab 200,00 m² - 10,0 bar 1x CHR Gesab 50,20 m² - 10,0 bar 2x CHO Gesab 121,70 m² - 10,0 bar |
|
Shaft generator |
1x 900 kVA - 720 kW |
|
Generators |
3x Mitsubishi MAS 850-S main diesel generatorsets each 988 kVA - 790 kW - 1.125 hp at 1.800 rpm |
|
Emergency generator |
1x Diesel generatorset 250 kVA - 200 kW - 345 hp |
|
Bow thruster |
1x Tunnel thruster 1650 AUX CP - 865 kW / 60Hz |
|
Number of cargo tanks |
16 |
|
Total cap. of tanks 98% |
16.548 m³ |
|
Slop tank capacity |
242 m³ |
|
Pumps |
9x Deepwell pumps DW 200/250 cargo pumps multi-suction 450 m³/h |
|
Tank capacities |
Fuel oil: 1.236,4 m³ Marine gas oil: 610 m³ Ballast water: 6.636 m³ LNG: 630 m³ Fresh water: 325 m³ |
|
Manager |
Tärntank Ship Management AB Donsö hamnväg 24 430 82 Donsö Sweden |
|
Owner |
Terntank Rederi A/S Vestre Strandvej 10 9990 Skagen Denmark |
|
Latest data adjustment |
07 May 2021 |
