Westerschelde 27 December 2017 |
 |
 |
 |
 |
|||
| Westerschelde 07/12/19 | Westerschelde 07/12/19 | Westerschelde 27/12/17 | WS 27/12/17 | |||
|
Name |
MED ARCITIC |
|
Previous names |
2009 - 2009 Nordic Harmony 2009 - 2015 Med Arcitic 2015 - 2015 Sea Dolphin |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9410545 |
|
Call sign |
9HA2147 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
5.651 t |
|
DWT |
8.280 t |
|
NT |
2.602 t |
|
Length |
123,90 m overall 116,27 m between perpendiculars |
|
Breadth |
17,20 m |
|
Draught |
Summer: 7,24 m 4,83 m in ballast |
|
Height from keel to mast |
36,62 m |
|
Air draft |
31,50 m in ballast 29,38 m loaded |
|
Freeboard |
1.977 mm |
|
Depth |
9,20 m moulded |
|
Speed |
Service: 13,2 knots |
|
Built |
2009 |
|
Date of completion |
29/06/2009 |
|
Builder |
Med Marine Kilavuzluk Ve Romorkaj Hizmetleri Insaat Sanayi Ve Tic. A.S. (Usmed Shipyard) Karadeniz Eregli Turkey |
|
Yard number |
USMED 03 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK-Caterpillar 8M32C - 8 cylinder combustion engine 4.000 kW / 5.435 hp at 600 rpm Built: 19/11/2007 Builder: Caterpillar Motoren GmbH & Co. KG - Germany |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
2x CHO S-MAN AB 65,00 m² - 10,0 bar 1x CHR S-MAN AB 48,00 m² - 10,0 bar |
|
Generators |
3x Main diesel generatorsets each 731 kVA - 585 kW - 842 hp |
|
Bow thruster |
576,65 bhp / 430 KW |
|
Number of cargo tanks |
12 + 2 slop |
|
Number of segregations |
14 Double valves |
|
Total capacity of tanks 98% |
8.918,51 m³ |
|
Slop tank capacity 98% |
184,17 m³ |
|
Pumps |
12x Centrifugal cargo pumps each 350 m³/h 2x Centrifugal cargo pumps each 100 m³/h 2x Deepwell ballast pumps each 500 m³/h |
|
Manifolds |
Distance from bow to centre manifold: 61,61 m Distance from stern to centre manifold: 54,71 m Distance between manifolds: 750 mm Distance from ship side to manifold: 2,65 m Distance from deck / tray to manifold: 2.115 mm |
|
Tank capacities |
Fuel oil: 343,59 m³ Ballast: 3.824,44 m³ |
|
Lifting equipment |
1x Crane - SWL 5,0 t |
|
Crew size |
18 |
|
Operator |
YMN Tanker Deniz Isletmeciligi A.S. Altunizade Mah. Ord. Prof. Fahrettin Kerim Gökay Cad. Denizciler İş Merkezi, A Blok No:18/1 34662 Üsküdar Istanbul Turkey |
|
Registered Owner |
Sea Tankers 2 Ltd. 198 Old Bakery Street Valletta Malta |
|
Latest data adjustment |
19 March 2023 |
