Antwerpen 16 August 2017
Name
SONGA CHALLENGE
Previous names
2009 - 12.2013 Global Challenge
Type
Oil & chemical tanker
IMO-number
9409510
Call sign
V7CZ8
Flag
Marshall Islands
Port of registry
Majuro
Previous flags
2009 - 2013 Hong Kong
GT
11.623 t
DWT
Summer: 19.993,30 t
NT
6.056 t
Length
145,53 m overall
Breadth
23,73 m extreme
Draft
9,71 m
Reg. dimensions L x B x D
137,92 x 23,70 x 13,35 m
Rule dimension L x B x D
137,00 x 23,70 x 13,35 m
Freeboard
Summer: 3.670 mm
Depth
13,35 m moulded
Speed
14,07 knots
Built
2009
Keel laid
13.04.2009
Launch date
13.06.2009
Date of completion
20.08.2009
Builder
Usuki Shipyard Co., Ltd.
Usuki Japan
Yard number
1717
Hull material
Steel
Hull type
Double hull
Watertight bulkheads
Transverse: 14
Continuous decks
1
Main engine
1x MAN-B&W-Hitachi 6S42MC - 2 stroke single acting 6 cylinder 420 x 1.764 mm diesel engine 6.150 kW / 8.360 hp at 136,0 rpm
Build: 04.2009
Manufacturer: Hitachi Zosen Corporation, Onomichi - Japan
Propellers
1x Fixed propeller
Boilers
1x Auxiliary water tube boiler - 9,0 kg/cm²
Heating surface: 184,2 m²
2x Economizer EGE - 14,0 kg/cm²
Heating surface: 129,9 m²
Build: 03.2009
Manufacturer: Miura Co., Ltd., Matsuyama - Japan
Generators
3x Main diesel generatorsets each 575 kVA / 450 Volt
Bow thruster
1x 610 kW
Number of cargo tanks
22
Cargo tank capacity 98%
Liquid: 22.192,04 m³
Slop tank capacity 98%
Liquid: 691,21 m³
Tank capacities
Fuel oil: 974,1 m³
MDO: 148,68 m³
Fresh water: 663,8 m³
Water ballast: 7.785,7 m³
Manager
Songa Shipmanagement Ltd.
Owner
Songa Chemical AS
Group
Blystad Group
Haakon VIIs gt. 1, 11th floor 0161 Oslo Norway
Latest data adjustment
05 December 2017
