Westerschelde 17 April 2017 |
 |
 |
|
| Westerschelde 27/04/17 | Westerschelde 14/01/17 | |
|
Name |
HIGH STRENGTH |
|
Type |
Crude oil/Product carrier |
|
IMO-number |
9424651 |
|
Call sign |
3FRP3 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
28.231 t registered |
|
DWT |
Summer: 46.592 t |
|
NT |
12.822 t registered |
|
Length |
179,90 m overall 172,00 m between perpendiculars |
|
Breadth |
32,20 m moulded |
|
Draught |
Summer: 12,79 m |
|
Freeboard |
6.484 mm |
|
Depth |
19,25 m moulded |
|
Speed |
15,7 knots |
|
Built |
2009 |
|
Keel laid |
13/02/2009 |
|
Delivery date |
30/10/2009 |
|
Builder |
Naikai Zosen Corporation Setoda Shipyard Onomichi Japan |
|
Yard number |
725 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
13 |
|
Main engine |
1x MAN-B&W/Hitachi 6S50MC-C - 2 stroke 6 cylinder 500 x 2.000 mm combustion engine 9.480 kW / 12.89 hp at 127,0 rpm Manufacturer: MAN-B&W Hitachi Zosen Ariake Works (Hitachi Zosen Diesel & Engineering Co., Ltd. - Japan) |
|
Propellers |
1x Fixed pitch propeller - aft at 127,0 rpm Manufacturer: Kamome Propeller |
|
Boilers |
1x Auxiliary boiler - 9,0 bar 1x Exhaust Gas economizer - 13,0 bar Manufacturer: Miura |
|
Generators |
3x Main diesel generatorsets each 1.062 kVA - 850 kW - 1.318 hp |
|
Emergency generator |
1x Diesel generatorset 100 kVA - 80 kW - 109 hp |
|
Number of cargo tanks |
12 |
|
Cargo oil capacity 100% |
55.032,1 m³ |
|
Number of slop tanks |
2 |
|
Number of pumps |
4x Cargo pups each 800 m³/h |
|
Number of tanks |
Ballast: 14 Lubricating oil: 9 Fuel oil: 8 Diesel oil: 5 Fresh water: 4 Sludge: 2 Waste water: 1 Sewage: 1 Slop: 1 |
|
Tank capacities |
Diesel Oil: 783,4 m³ Freshwater: 329 m³ Fuel Oil: 1.677,85 m³ Lube Oil: 93,96 m³ Tank Ballast: 20.059,44 m³ |
|
Lifting equipment |
1x Cargo hose handling crane - SWL 10,0 t 1x Engine crane - SWL 2,0 t 1x General use crane - SWL 4,0 t |
|
Manager |
Ishima - International Ship management Republic of Singapore |
|
Operator |
Ishima Pte Ltd 6 Battery Road, #34-01 Singapore, 049909 Republic of Singapore |
|
Registered owner |
DM Shipping D.A.C. Dublin Ireland |
|
Renamed |
04/2019 Di Matteo Republic of Singapore, Singapore City - Call sign: 9V6317 Owner: Minsheng Yangji (Tianjin) Shipping Leasing Company Limited Operator: Ishima Pte Ltd. |
|
Latest data adjustment |
09 August 2023 |
