| Westerschelde 04 January 2017 |
 |
 |
|
| Westerschelde 04/01/17 | Westerschelde 29/04/17 | |
|
Name |
BERGEN NORDIC |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9257591 |
|
Call sign |
LMFQ3 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
2.490 t |
|
DWT |
Summer: 3.535 t |
|
NT |
1.128 t |
|
Length |
95,92 m overall 87,02 m between perpendiculars |
|
Breadth |
14,43 m extreme |
|
Draught |
Summer: 5,76 m fully loaded |
|
Keel to masthead |
30,00 m |
|
Air draft |
26,00 m |
|
Depth |
7,00 m |
|
Speed |
Service: 13,0 knots |
|
Built |
2003 |
|
Keel laid |
28/08/2001 |
|
Launch date |
03/08/2002 |
|
Date of completion |
22/04/2003 |
|
Builder |
Gisan Gemi Ins. Istanbul Turkey |
|
Yard number |
029 |
|
Hull material |
Steel |
|
Hull type |
Double bottom Double side |
|
Bulkheads |
Transverse: 11 |
|
Main engine |
1x MAN-B&W ALPHA 6L27/38 - 6 cylinder combustion engine 2.040 kW at 800 rpm |
|
Propellers |
1x Controllable pitch propeller 4 blades - Diameter 3.300 mm |
|
Rudder |
Gurdesan Flap rudder |
|
Boilers |
2x Thermal oil heater, oil fired - Garioni Nav TH 1500 |
|
Shaft generator |
1x AVK DSU 74M1-4 - 870 kW |
|
Generators |
3x MAN D2842LE301 main diesel generatorset each 470 kW |
|
Emergency generator |
1X MAN D866 E diesel generatorset |
|
Thruster |
1x Rolls Royce 300 kW, forward 1x Brunvoll 280 kW, aft |
|
Number of cargo tanks |
14 |
|
Cargo tank capacity 98% |
CT2P&SB: 612 m³ CT3P&SB: 416 m³ CT4P&SB: 759 m³ CT5P&SB: 761 m³ CT6P&SB: 847 m³ CT7P&SB: 408 m³ CT1/Slop P&SB: 152 m³ Total: 3.955 m³ ex. slop tank |
|
Number of slop tanks |
1 |
|
Slop tank capacity 98% |
152 m³ |
|
Number of segregations |
14 |
|
Pumps |
12x Framo Hydraulic deepwell cargo pumps each 200 m³/h 2x Framo hydraulic deepwell cargo pumps each 100 m³/h |
|
Pumping capacity |
2.000 m³/h |
|
Tank coating |
Marineline / Modified epoxy |
|
Manifolds |
Bow to centre manifold: 51,00 m |
|
Tank capacities |
Ballast: 1.597,51 m³ |
|
Lifting equipment |
1x Hose crane - SWL 3,0 t Outreach 14,50 m |
|
Manager |
Bergen Tankers AS Klampavikvegen 52 5300 Kleppestø Norway |
|
Registered owner |
Bergen Tankers AS |
|
Renamed |
09/2017 Norsel Norway, Tromsø - Call sign: LMFQ3 Owner: Norvarg AS, Tromsø - Norway Manager: Marine Supply AS, Tromsø - Norway |
|
Latest data adjustment |
18 April 2023 |
