Westerschelde 14 December 2015 |
|
Name |
TROVIKEN |
|
Previous names |
2006 Build as: Gansea 01.2006 - 03.2012 Trochus |
|
Type |
Crude and oil products carrier |
|
IMO-number |
9285859 |
|
Call sign |
C6ZT9 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
62.806 t |
|
DWT |
Summer: 115.340,9 t |
|
NT |
34.551 t |
|
Length |
249,99 m overall 239,00 m between perpendiculars |
|
Breadth |
43,80 m moulded |
|
Draught |
14,90 m |
|
Freeboard |
6.418 mm |
|
Depth |
21,30 m moulded |
|
Speed |
16,4 knots |
|
Built |
2006 |
|
Keel laid |
24.12.2004 |
|
Delivery date |
04.01.2006 |
|
Builder |
Samsung Heavy Industries Co., Ltd. Geoje Shipyard |
|
Yard number |
1504 |
|
Hull material |
Ordinary strength steel High strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Water tight: 11 Oil tight: 1 |
|
Main engine |
1x 6S60MC-C Mk7 - 6 cylinder 600 x 2.292 mm diesel engine 13.560 kW at 105,0 rpm Manufacturer: Doosan Engine Co., Ltd.(B&W), Changwon - South Korea |
|
Propellers |
1 |
|
Boilers |
1x Exhaust gas boiler - 21,57 bar Manufacturer: Kangrim Industries Co., Ltd. 2x Auxiliary boiler - 17,65 bar Manufacturer: Mitsubishi Heavy Industries, Ltd. |
|
Generators |
3x 6L23/30H main diesel generatorsets each 914 kVA |
|
Number of cargo tanks |
12 |
|
Cargo oil capacity 100% |
115.641,8 m³ |
|
Number of tanks |
Ballast: 14 Lubricating oil: 6 Diesel oil: 4 Fuel oil: 4 Sludge: 4 Fresh water: 2 Chain: 2 Slop: 2 |
|
Tank capacities 100% |
Diesel Oil: 598,9 m³ / 539,01 t Fuel Oil: 2.348,2 m³ / 2.301,23 t Lube Oil: 104,9 m³ / 94,41 t Tank Ballast: 78.411,6 m³ / 80.371,89 t |
|
Lifting equipment |
1x Engine room crane - SWL 4,0 t 1x Hose handling crane - SWL 15,0 t 1x Provision crane - SWL 1,0 t 1x Provision crane - SWL 4,0 t |
|
Previous managers |
Troviken LLC Ajeltake Road, Ajeltake Island Majuro, MH96960 Marshall Islands |
|
Operator |
Wallem Shipmanagement Limited |
|
Owner |
Viken Shipping AS |
|
Registered owner |
Troviken LLC |
|
Latest data adjustment |
15 March 2017 |
