Name |
Till Jacob |
|
Type |
Crude oil / Product carrier |
|
IMO-number |
9482861 |
|
Call sign |
A8XG6 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
43.904 t Suez: 45.933,62 t |
|
DWT |
Summer: 75.563,5 t |
|
NT |
21.967 t Suez: 44.614,33 t |
|
Light ship weight |
15.751 t |
|
Length |
228,51 m overall 221,21 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Freeboard |
6.519 mm |
|
Depth |
21,20 m moulded |
|
Built |
2012 |
|
Delivery date |
28.02.2012 |
|
Builder |
Dalian Shipbuilding Industry Co Ltd. |
|
Yard number |
PC760-21 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
11 |
|
Main engine |
1x DMD China / MAN B&W 6S60MC - 6 cylinder 600 x 2.790 mm diesel engine 12.240 kW at 105,0 rpm Manufacturer: Dalian Marine Diesel Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller - 4 Blades, right handed – aluminium bronze - diameter 7,00 m Manufacturer: HHI Engine & Machinery Div. |
|
Boilers |
2x Oil-fired auxiliary boiler Manufacturer: Aalborg Industries |
|
Generators |
Yanmar 6N21AL-UV - about 800 kW |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity 98% |
83.687 incl. slop tank |
|
Number of slop tanks |
2 |
|
Number of ROT |
1 Capacity: 215 m³ |
|
No. of segregations |
3x Centrifugal pump steam driven |
|
Discharge capacity |
6.000 m³/h |
|
Number of cargo pumps |
3 |
|
Number of ballast pumps |
2x Centrifugal pump, 1.000 m³ - Electric motor drive |
|
Number of tanks |
Ballast: 18 Fuel oil: 9 Lubricating oil: 8 Fresh water: 4 Waste water: 3 Diesel oil: 3 Chain: 2 Sludge: 2 Sewage: 1 |
|
Tank capacities |
Diesel Oil: 606,8 m³ - 98% Freshwater: 351,1 m³ - 100% Fuel Oil: 2.013,1 m³ - 98% Lube Oil: 191,8 m³ / 182,21 t Tank Ballast: 28.972,3 m³ / 29.696,60 t - 100 % |
|
Lifting equipment |
1x Cargo hose handling crane - SWL 15,0 t 1x Provision crane - SWL 4,0 t |
|
Manager |
Jacob Tank Dritte Beteiligungsgesellschaft MBH & C D-20095 Hamburg |
|
Operator |
Ernst Jacob (GmbH & Co. KG) |
|
Registered owner |
Jacob Tank Dritte Beteiligungsgesellschaft MBH & C |
|
Latest data adjustment |
03 August 2013 |
