Name |
SOMTRANS VII |
|
Type |
Inland tanker |
|
ENI-number |
02335789 |
|
Flag |
G.D. Luxembourg |
|
DWT |
3.746 t |
|
Length |
125,00 m |
|
Breadth |
11,45 m |
|
Draught |
3,70 m |
|
Built |
2015 |
|
Builder casco |
Kherson Shipyard Kherson Ukraine |
|
Builder completion |
Veka Shipbuilding B.V. Werkendam The Netherlands |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Mitsubishi S16R-C2MPTK diesel engine 1.250 kW / 1.700 hp at 1.600 rpm |
|
Gearbox |
1x Masson Marine W7350 - Reduction: 5,031:1 |
|
Propellers |
1x 5-bladed propeller - Diameter: 1.750 mm with nozzle Optima 1.712 mm |
|
Generators |
1x Caterpillar C18 diesel engine coupled with Stamford generator type HCM534 - 530 kVA 1x John Deere type 4045 diesel engine coupled with Stamford generator type UCM274 - 107 kVA 1xJohn Deere type 4045diesel engine coupled with Stamford generator 85 kVA |
|
Bow thruster |
1x Veth-Jet, type 4-K-1300 - 393 kW at 1.800 rpm |
|
Tank capacity 100% |
4.560 m³ |
|
Pumps |
12x Marflex MDPD-80 deepwell cargo pumps |
|
Pump capacity |
960 m³/h |
|
Lifting equipment |
1x Car crane |
|
Manager |
Somtralux N.V. Albertkanaalbaan 9 2110 Wijnegem Belgium |
|
Latest data adjustment |
02 April 2016 |
