Westerschelde 10 February 2016 |
 |
| Westerschelde 10/02/16 |
|
Name |
HAFNIA BERING |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9725603 |
|
Call sign |
9V3278 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
24.120 t Suez: 25.484,72 t |
|
DWT |
Summer: 39.000 t |
|
NT |
10.359 t Suez: 21.671,99 t Panama: 20.116 t |
|
Length |
184,26 m overall 176,00 m between perpendiculars |
|
Breadth |
27,40 m extreme |
|
Draught |
10,60 m |
|
Keel to masthead |
46,40 m |
|
Air draft full mast |
Lightship: 43,95 m Normal ballast: 39,65 m At loaded summer deadweight: 36,00 m |
|
Freeboard |
Summer: 5.713 mm Winter: 5.961 mm |
|
Depth |
17,60 m moulded |
|
Speed |
Max.: 15,0 knots 12,0 knots economic |
|
Built |
2015 |
|
Delivery date |
13.04.2015 |
|
Builder |
Hyundai Mipo Dockyard |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Hyundai/MAN B&W - 7.290 kW |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Kangrim capacity 18 t/h |
|
Generators |
3x HHI-EMD main diesel generatorsets each 1.070 kW |
|
Number of tanks |
12 |
|
Cargo tank capacity 98% |
Tank 1 P/S: 2.572,87 m³ / 2.563,89 m³ Tank 2 P/S: 3.648,77 m³ / 3.645,60 m³ Tank 3 P/S: 3.712,10 m³ / 3.717,49 m³ Tank 4 P/S: 3.712,11 m³ / 3.717,50m³ Tank 5 P/S: 3.712,11 m³ / 3.717,49 m³ Tank 6 P/S: 3.452,69 m³ / 3.457,11 m³ Total P/S: 20.810,65 m³ / 20.819,08 m³ Total:41.629,73 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
Slop P/S: 536,07 m³ / 334,93 m³ Total: 871 m³ |
|
Residual/retention oil tank 98% |
167,91 m³ |
|
Pumps |
10x Framo cargo pumps each 500 m³/h 2x Framo cargo pumps each 300 m³/h 2x Framo cargo pumps each 200 m³/h 2x Framo ballast pumps each 750 m³/h |
|
Max. loading rate |
3.000 m³/h |
|
Manifolds |
Bow to centre manifold: 92,58 m Stern to centre manifold: 91,68 m Distance bridge front to centre of manifold: 57,63 m Distance between cargo manifold centres: 2.000 mm Distance ships rail to manifold: 4.500 mm Distance manifold to ships side: 4.600 mm Top of rail to centre of manifold: 700 mm Distance main deck to centre of manifold: 2.100 mm |
|
Tank capacities |
Fuel oil: 1.176 m² Diesel oil: 217,8 m³ Gas oil: 1.394,2 m³ |
|
Lifting equipment |
1x Crane - SWL 10,0 t |
|
Technical operator |
Thome Ship Management |
|
Commercial operator |
Hafnia Handy Pool Management ApS |
|
Registered owner |
Hafnia Tankers Shipholding Singapore Pte Ltd. |
|
Latest data adjustment |
28 February 2016 |
