Westerschelde 07 December 2019 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 07/12/19 | Westerschelde 07/12/19 | Westerschelde 07/12/19 | Westerschelde 26/12/15 | Westerschelde 26/12/15 | Vlissingen 14/12/17 | |||||
|
Name |
EXCELLO |
|
Type |
Tanker for oil & chemicals |
|
IMO-number |
9308558 |
|
Call sign |
SJMG |
|
Flag |
Sweden |
|
Port of registry |
Donsö |
|
GT |
13.798 t |
|
DWT |
Summer: 19.999 t |
|
NT |
6.521 t |
|
Length |
155,70 m overall 140,38 m between perpendiculars |
|
Breadth |
23,73 m extreme |
|
Draught |
9,76 m |
|
Keel to mast |
44,10 m |
|
Depth |
12,80 m moulded |
|
Speed |
14,0 knots |
|
Built |
2008 |
|
Keel laid |
23/11/2006 |
|
Launch date |
16/07/2007 |
|
Date of completion |
23/05/2008 |
|
Builder |
Shanghai Edward Shipbuilding Co. Ltd. 1 Nan Ma Tou Road Pudong New Area 200125 Shanghai China |
|
Yard number |
H137 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse: 9 Longitudinal: 3 |
|
Main engine |
3x Wärtsilä 6L32 CR combustion engine couples with Siemens generators each 2.880 kW 1x Wärtsilä 4L20 diesel engine couples with Siemens generator 690 kW Total: 9.720 kW Supplying a propulsive electric motor which drives an azimuth thruster |
|
Propulsion |
2x ABB Azipod 3.200 kW propulsion propellers |
|
Boilers |
2x Thermal oil heater, exhaust heated type TOH3800V550 4x Thermal oil heater, exhaust heated type EGH600V40 |
|
Emergency generator |
1x Volvo Penta D25-MS diesel generatorset 450 kW |
|
Bow thruster |
1x Schottel STP 1010 LK tunnel thruster 850 kW |
|
Number of tanks |
14 |
|
Segregations |
14 |
|
Cargo tank capacity |
22.650 m³ |
|
Pumps |
14 x Centrifugal cargo pumps each 250 m³/h 2x Ballast pumps |
|
Tank capacities |
Heavy fuel: 726 m³ MDO: 96 m³ Fresh water: 253 m³ Ballast: 8.496 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 60 mm |
|
Lifting equipment |
2x Cranes - SWL 10,0 t each |
|
Number of cabins |
17x For a crew of at least 13 people |
|
ISM & commercial manager |
Rederi AB Donsötank Donsö hamnväg 18 430 82 Donsö Sweden |
|
Registered owner |
Donsö Shipping AB c/o Rederi AB Donsötank Donsö hamnväg 18 430 82 Donsö Sweden |
|
Latest data adjustment |
13 June 2023 |
