Westerschelde 10 November 2015 |
 |
 |
 |
||
| Westerschelde 10/11/15 | Westerschelde 10/11/15 | Westerschelde 03/01/16 | ||
|
Name |
LILLO SWAN |
|
Previous names |
2007 - 05/2012 Erria Julie |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9390329 |
|
Call sign |
9HDO9 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
3.300 t |
|
DWT |
Summer: 4.696,16 t |
|
NT |
1.424 t |
|
Length |
99,90 m overall 94,10 m between perpendiculars |
|
Breadth |
15,00 m moulded |
|
Draught |
Summer: 6,04m 4,03 m ballast |
|
Height from keel to mast |
33,56 m |
|
Air draft |
29,00 m ballast 27,50 m loaded condition |
|
Depth |
7,40 m moulded |
|
Speed |
13,5 knots ballast 12,0 knots loaded |
|
Built |
2007 |
|
Keel laid |
14/12/2006 |
|
Launch date |
07/06/2007 |
|
Date of completion |
23/11/2007 |
|
Builder |
Celiktrans Shipbuilding (Celiktrans Deniz Insaat Ltd. Sti) Istanbul Turkey |
|
Yard number |
32 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
12 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M25 - 4 stroke 8 cylinder 255 x 400 mm combustion engine 2.640 kW / 3.589 hp at 750 rpm Builder: MaK Maschinenbau Kiel AG - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
2x CHO Euroboilers S-MAN AB 25,00 m² / 10,0 bar 1x CHR Euroboilers S-MAN AB 38,00 m² / 10,0 bar |
|
Generators |
3x MAN D2876 LE 301 main diesel generatorsets each 456 kVA - 365 kW - 530 hp |
|
Emergency generator |
1x MAN D0824 LE 201 diesel generatorset 124 kVA - 99 kW - 155 hp |
|
Bow thruster |
1x 299,77 kW |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity 98% |
4.967,60 m³ |
|
Slop tank capacity 98% |
120,30 m³ |
|
Segregations |
13 |
|
Pumps |
12x Cargo pumps 220 m³/h each 2x Cargo pumps 110 m³/h each 2x Ballast pumps 200 m3/h each |
|
Manifolds |
Distance from bow to centre manifold: 44,00 m Distance from stern to centre manifold: 55,90 m Distance between manifolds: 0,66 m Distance from ship side to manifold: 2,95 m Distance from deck / tray to manifold: 1,88 / 0,95 m |
|
Tank capacities |
Ballast: 1.900,5 m³ Fuel: 354,67 m³ |
|
Anchor equipment |
Length: 467,50 m Diameter: 38 mm |
|
Lifting equipment |
1x Hose crane - SWL 5,0 t 1x MOB crane - SWL 2,0 t |
|
Manager |
Uni-Tankers A/S Turbinevej 10 5500 Middelfart Denmark |
|
Previous managers |
2007 - 2012 Erria A/S |
|
Registered owner |
Uni-Tankers M/T "LILLO SWAN" ApS |
|
Previous owners |
2007 - 2012 Erria Tankers Ltd. 2012 - 2012 Uni-Tankers A/S |
|
Latest data adjustment |
11 February 2024 |
