Westerschelde 15 May 2019 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 29/04/19 | Westerschelde 28/04/19 | Westerschelde15/04/12 | Westerschelde15/04/12 | Westerschelde15/04/12 | Westerschelde 13/08/18 | |||||
|
Name |
HEINRICH |
|
Type |
Chemical tanker |
|
IMO-number |
9242730 |
|
Call sign |
ZDFF7 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
Previous flags |
2002 - 2007 Dominica |
|
GT |
4.401 t |
|
DWT |
Summer: 6.711,5 t |
|
NT |
2.063 t |
|
Length |
114,00 m overall 106,50 m between perpendiculars |
|
Breadth |
16,90 m extreme |
|
Draught |
6,65 m |
|
Keel to mast end |
32,40 m |
|
Depth |
8,40 m |
|
Speed |
14,5 knots |
|
Built |
2002 |
|
Keel laid |
15/09/2001 |
|
Launch date |
27/04/2002 |
|
Date of completion |
02/08/2002 |
|
Builder |
Selah Shipyard (Selah Makina Sanayi ve Ticaret Shipyard) Tuzia Istanbul Turkey |
|
Yard number |
034 |
|
Hull material |
Steel |
|
Watertight bulkheads |
Double hull |
|
Main engine |
1x MaK 8M32C - 4 stroke 8 cylinder 320 x 480 mm combustion engine 3.842 kW / 5.224 hp at 600 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
2x Auxiliary boiler, exhaust gas heated EXV 6-30 2x Thermal oil heater, oil fired S 25-VO-13 |
|
Generators |
3x MAN D2842LE diesel generatorsets |
|
Emergency generator |
1x MAN D2866E diesel generatorset |
|
Bow thruster |
1x 300 kW |
|
Number of tanks |
13 |
|
Cargo tank capacity |
7.287 m³ |
|
Number of pumps |
12x Cargo pumps each 200 m³/h 1x Cargo pump 120 m³/h |
|
Tank capacities |
Ballast: 2.553,49 m³ |
|
Anchor equipment |
Length: 496 m Diameter: 50 mm |
|
Lifting equipment |
1x Crane - SWL 2,0 t 1x Crane - SWL 3,0 t |
|
ISM & commercial manager |
Carl F. Peters (GmbH & Co.) KG Kurze Mühren 13 20095 Hamburg Germany |
|
Registered owner |
Reederei TMS "HEINRICH" GmbH & Co. KG Care of Carl F Peters (GmbH & Co) KG Kurze Muehren 13 20095 Hamburg Germany |
|
Renamed |
2022 Brave Barbados, Bridgetown - Call sign: 8PBN9 Owner: Heinrich Shipping Services Inc. Manager: Callista Shipping Services Inc. |
|
Latest data adjustment |
19 July 2022 |
