Antwerpen 14 May 2015 |
|
Name |
FRISIA |
|
Previous names |
2003 - 2009 Vopak. Frisia 2009 Frisia |
|
Type |
Inland tanker |
|
ENI-number |
02325999 |
|
Flag |
The Netherlands |
|
GT |
1.224 t |
|
DWT |
Summer: 1.709 t |
|
Length |
81,30 m |
|
Breadth |
10,24 m |
|
Draught |
3,20 m |
|
Air draft |
4,50 m |
|
Depth |
4,90 m |
|
Built |
2003 |
|
Date of completion |
01.10.2003 |
|
Builder |
Maas Shipyard |
|
Yard number |
5 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
11 |
|
Continuous decks |
1 |
|
Main engine |
1x Caterpillar 3512 (B) DI-TA electronic - 4 stroke 12 cylinder 170 x 190 diesel engine - 1.014 kW / 1.378 hp at 1.600 rpm Built: 2003 Builder: Caterpillar Inc., Lafayette, IN - USA |
|
Propellers |
1x Screw propeller solid - aft at 325 rpm |
|
Boilers |
1x CHO Harms GmbH - 9,0 bar |
|
Electric installations |
Power voltage: 400 V Lighting voltage: 230 V Frequency: 50 Hz |
|
Generators |
1x Diesel generatorset 360 kVA - 288 kW - 538 hp |
|
Bow thruster |
1x Cummins 340 hp - van Tiem |
|
Number of cargo tanks |
6 |
|
Tank capacity 100% |
1.888 m³ |
|
Charterer |
Interstream Barging B.V. |
|
Owner |
Vof. Sytema |
|
Previous names & owners |
2003 Vopak. Frisia - Vof. Sytema, Wergea - The Netherlands 2009 Frisia - Vof. Sytema, Wergea - The Netherlands |
|
Latest data adjustment |
19 June 2015 |
