| Vlissingen, The Netherlands 04 May 2015 |
 |
 |
|
| Vlissingen 04/05/15 | Vlissingen 04/05/15 | |
|
Name |
EMMANUEL TOMASOS |
|
Type |
Oil / Chemical tanker |
|
IMO-number |
9240720 |
|
Call sign |
C6SS7 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
23.217 t |
|
DWT |
Summer: 37.113,6 t |
|
NT |
10.111 t |
|
Length |
182,55 m overall 175,00 m between perpendiculars |
|
Breadth |
27,34 m 27,74 m extreme |
|
Draught |
11,22 m |
|
Heel to mast |
46,00 m |
|
Freeboard |
Summer: 5.514 mm |
|
Depth |
16,70 m |
|
Speed |
14,6 knots |
|
Built |
2002 |
|
Keel laid |
21.04.2002 |
|
Launch date |
16.07.2002 |
|
Date of completion |
30.10.2002 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. |
|
Yard number |
0050 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse: 8 Longitudinal: 1 |
|
Main engine |
1x B&W/Hyundai 6S60MC-C - 6 cylinder diesel engine 9.466 kW / 12.870 hp at 127 rpm Manufacturer: Hyundai Engine & Machinery Co.Ltd. (B&W), Ulsan - South Korea |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated AV-6 1x Auxiliary boiler, oil/gas fired Mission OL Builder: Aalborg Industries A/S |
|
Generators |
3x MAN B&W 6L23/30 diesel generatorsets |
|
Emergency generator |
1x Cummins LTA-10-D(M) diesel generatorset |
|
Number of tanks |
12 |
|
Cargo tank capacity 100% / 98% |
No 1 Cargo tank (P): 3.069,8 m³ / 3.008,4 m³ No 1 Cargo tank (S): 3.069,8 m³ / 3.008,4 m³ No 2 Cargo tank (P): 3.666,3 m³ / 3.593,0 m³ No 2 Cargo tank (S): 3.666,3 m³ / 3.593,0 m³ No 3 Cargo tank (P): 3.658,2 m³ / 3.585,1 m³ No 3 Cargo tank (S): 3.658,2 m³ / 3.585,1 m³ No 4 Cargo tank (P): 3.670,8 m³ / 3.597,4 m³ No 4 Cargo tank (S): 3.670,8 m³ / 3.597,4 m³ No 5 Cargo tank (P): 3.658,2 m³ / 3.585,1 m³ No 5 Cargo tank (S): 3.658,2 m³ / 3.585,1 m³ No 6 Cargo tank (P): 3.370,0 m³ / 3.302,6 m³ No 6 Cargo tank (S): 3.370,0 m³ / 3.302,6 m³ Slop tank (P): 441,1 / 432,3 m³ Slop tank (S): 441,1 / 432,1 m³ Grand total: 43.068,9 m³ / 42.207,5 m³ |
|
Number of slop tanks |
2 |
|
Number of segregations |
6x With double valve |
|
Pumps |
12x Deepwell cargo pumps 10x 500 m³/h 2x 300 m²/h 2x Slop pumps 2 x 150 m³/h |
|
Manifolds |
Distance rail to manifolds: 4,60 m Manifold height of sea level upon completion of discharging: 11,96 m |
|
Tank capacities |
Fuel oil: 1.254,8 m³ Marine diesel oil: 176,4 m³ Fresh water: 224,6 m³ Ballast capacity:18.915,3 m³ |
|
Anchor equipment |
Length: 605,00 m Diameter: 66 mm |
|
Lifting equipment |
1x Crane - SWL 10,0 t |
|
Manager |
Super Eco Tankers Management Inc. |
|
Owner |
Impala Maritime Ltd. c/o Super Eco tankers Management Inc. |
|
Latest data adjustment |
16 May 2015 |
