Antwerpen 24 July 2014 |
 |
| Antwerpen 24/07/14 |
|
Name |
AYLA |
|
Previous names |
1956 Kreuzingen - EU number: 7000505 1970 Haniel Tank 2 Margarete-B 1976 Ayla |
|
Type |
Inland tanker |
|
ENI-number |
04006770 |
|
Flag |
Germany |
|
Port of registry |
Ruhrort |
|
Tonnage |
1.225,57 t |
|
Length |
85,00 m |
|
Breadth |
8,25 m |
|
Draught |
2,60 m |
|
Depth |
2,62 m |
|
Built |
1956 06.1976 Ship lengthened |
|
Launch date |
10.1956 |
|
Date of completion |
11.1956 |
|
Builder |
Ruhrorter Schiffswerft und Maschinenfabrik GmbH |
|
Yard number |
154 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight bulkheads |
12 |
|
Continuous decks |
1 |
|
Main engine |
1x Deutz TBD 620 V8 - 4 stroke 8 cylinder 170 x 195 mm diesel engine 808 kW / 1.100 hp at 1.800 rpm Year of manufacture: 2003 Manufacturer : Deutz AG Werk Mannheim |
|
Propellers |
1x Solid propeller - aft at 368 rpm |
|
Electric installations |
1x Plant 380/220 V - 37 kVA 1x Plant 380/220 V - 56 kVA 1x Plant 380/220 V - 100 kVA 1x Plant 24/220 V - 1,5 kW 1x Plant 24/220 V - 2,7 kW |
|
Generators |
1x Main generator 100 kVA 1x Main generator 56 kVA 1x Main generator 37 kVA 1x Generator 2,7 kW 1x Generator 1,5 kW |
|
Compressed air receivers |
1x Receiver 500 litres - 30,0 bar |
|
Bow thruster |
1x Fixed pitch propeller LIPS - 202 kW, forward |
|
Manager |
TMS Ayla UG |
|
Owner |
Saban Ergueney |
|
Previous names & Owners |
1956 Kreuzingen - Franz Haniel AG, Basel - Switzerland 1970 Haniel Tank 2 - Franz Haniel GmbH, Dbg-Ruhrort - Germany Margarete-B - S. Bauer, Dillendorf Lieberbach - germany 1976 Ayla - Saban Ergüney, Duisburg - Germany |
|
Latest data adjustment |
13 February 2015 |
