Westerschelde 18 August 2018 |
 |
 |
 |
 |
|||
| Westerschelde 19/04/15 | Westerschelde 27/07/14 | Westerschelde 31/01/20 | Westerschelde 31/01/20 | |||
|
Name |
EKFORS |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9255878 |
|
Call sign |
LADX7 |
|
Flag |
Norway |
|
Port of registry |
Arendal |
|
Previous flags |
2003 - 2007 Sweden |
|
GT |
8.829 t |
|
DWT |
Summer: 13.702 t |
|
NT |
4.172 t |
|
Length |
134,71 m overall 126,99 m between perpendiculars |
|
Breadth |
20,83 m extreme |
|
Draught |
8,61 m |
|
Depth |
11,00 m to upper deck |
|
Keel to mast end |
37,40 m |
|
Speed |
Service: 13,5 knots ballast: 14,5 knots |
|
Built |
2003 |
|
Keel laid |
26/06/2002 |
|
Launch date |
17/03/2003 |
|
Date of completion |
12/12/2003 |
|
Builder |
Jiangnan Shipbuilding (Group) Co. Shanghai China |
|
Yard number |
H2289 |
|
Hull material |
Steel |
|
Hull type |
Double skin |
|
Bulkheads |
Longitudinal: 3 |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W 6S42MC - 2 stroke 6 cylinder 420 x 1.764 mm combustion engine 7.296 bhp / 5.366 kW at 120,0 rpm |
|
Propellers |
1x Controllable pitch propeller - aft at 120,0 rpm Diameter: 4,90 m |
|
Boilers |
1x Thermal oil heater, exhaust heated 2x Thermal oil heater, oil fired |
|
Generators |
4x MAN 5L16/24 main diesel generatorsets each 500 kW at 1.200 rpm |
|
Emergency generator |
1x Volvo Penta TAMD74 diesel generatorset |
|
Bow thruster |
1x 580 kW |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity |
14.434 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity |
170 m³ |
|
Number pumps |
12x Cargo pumps 330 m³/h each 2x Ballast pumps 500 m³/h each 2x Slop pumps 120 m³/h each |
|
Cargo discharge capacity |
± 1.980 m³/h |
|
Tank capacities |
Fuel oil 98%: 470 m³ Diesel oil: 89 m³ Fresh water: 110 m³ Water ballast: 5.451,5 m³ |
|
Lifting equipment |
1x Deck crane - SWL 5,0 t at 18,00 m |
|
Commercial manager |
Ektank AB Stora Badhusgatan 18-20 SE-411 21 Gothenburg Sweden |
|
ISM manager |
OSM Shipmanagement AS Svinoddveien 12 4836 Arendal Norway |
|
Previous managers |
2003 - 2006 Ektank AB |
|
Registered owner |
Ekships AB Care of Ektank AB Stora Badhusgatan 18-20 SE-411 21 Gothenburg Sweden |
|
Previous owner |
2003 - 2006 Ektank AB |
|
Latest data adjustment |
31 August 2022 |
