Westerschelde 10 May 2020 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 10/05/20 | Doel, Belgium 19/07/15 | Doel, Belgium 19/07/15 | Antwerpen, 01/04/14 | Westerschelde 12/12/17 | Westerschelde 19/07/18 | |||||
 |
 |
|||||||||
| Westerschelde 25/04/16 | Westerschelde 25/04/16 | |||||||||
|
Name |
ELSA ESSBERGER |
|
Type |
Chemical / Oil products tanker |
|
IMO-number |
9481001 |
|
Call sign |
CQJA |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
GT |
4.824 t |
|
DWT |
Summer: 5.297,5 t |
|
NT |
1.447 t |
|
Length |
99,40 m overall 93,70 m between perpendiculars |
|
Breadth |
16,50 m |
|
Draught |
6,90 m |
|
Keel to mast end |
34,60 m |
|
Freeboard |
3.509 mm |
|
Depth |
10,50 m moulded |
|
Speed |
14,1 knots |
|
Built |
2013 |
|
Keel laid |
09/03/2010 |
|
Date of completion |
22/05/2013 |
|
Builder |
Eregli Shipyard (Medmarine Kilavuzluk Ve Romorkaj Hizmetleri Insaat Sanayi Ve Tic. A.S) Karadeniz Eregli Turkey |
|
Yard number |
EREGLI 26 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Main engine |
1x STX/MAN-B&W 8L32/40 - 4 stroke single acting 8 cylinder 320 x 400 mm combustion engine 4.000 kW / 5.438 hp at 750 rpm Builder: STX Engine Co., Ltd. - South Korea |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
1x CHR Aalborg Industries 118,00 m² - 10,0 bar 2x CHO Aalborg Industries 57,00 m² - 13,0 bar |
|
Shaft generator |
3x Main diesel generatorsets 775 kVA - 620 kW - 842 hp |
|
Bow thruster |
1x Tunnel thruster 221 kW / 300 bhp, forward |
|
Number of cargo tanks |
12 |
|
Total capacity of tanks 98% |
6.224 m³ |
|
Number of pumps |
12x Cargo pumps each 150 m³/h |
|
Tank capacities |
Fuel: 356 m³ Diesel oil: 64 m³ Ballast: 2.484 m³ |
|
Crew size |
12 |
|
ISM & commercial manager |
John T.Essberger GmbH & Co. KG Palmaille 45 22767 Hamburg Germany |
|
Registered owner |
Kommanditgesellschaft Funfzehnte Oceania Schiffahrtsgesellsschaft mbH & Co. Care of John T Essberger GmbH & Co KG , Palmaille 45 22767 Hamburg Germany |
|
Latest data adjustment |
11 February 2022 |
