Westerschelde 26 March 2014 |
 |
|
| Zeebrugge 11/10/22 | |
|
Name |
ORAMALIA |
|
Previous names |
2007 - 09/2009 Amalia Theresa 2009 - 08/2013 NST Amalia |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9392640 |
|
Call sign |
CQAO3 |
|
Flag |
Portugal |
|
Port of registry |
Madiera |
|
Previous flags |
Gibraltar, Call sign: ZDNQ4 until 2021 |
|
GT |
3.933 t |
|
DWT |
Summer: 6.863 t |
|
NT |
1.940 t |
|
Length |
103,00 m overall 95,93 m between perpendiculars |
|
Breadth |
16,00 m |
|
Draught |
7,01 m |
|
Keelm to mast end |
28,31 m |
|
Freeboard |
1.712 mm |
|
Depth |
8,70 m |
|
Speed |
11,7 knots |
|
Built |
2007 |
|
Keel laid |
05/08/2005 |
|
Launch date |
20/04/2006 |
|
Date of completion |
16/03/2007 |
|
Builder |
Jiangsu Shenghua Shipbuilding Co.,Ltd. Nanjing (Jiangsu) China |
|
Yard number |
NSH406 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
11 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M25 - 4 stroke 8 cylinder 255 x 400 mm combustion engine 2.400 kW / 3.261 hp at 750 rpm Built: 2005 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 202 rpm |
|
Boilers |
1x CHO Qingdao Marine 56,00 m² - 9,0 bar 1x CHR Qingdao Marine 102,00 m² - 9,0 bar |
|
Electric installations |
Power voltage: 440 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Shaft generator |
1x 750 kVA - 600 kW |
|
Generators |
1x Diesel generatorset 200 kVA - 160 kW - 217 hp 2x Diesel generatorsets each 525 kVA - 420 kW - 571 hp |
|
Number of cargo tanks |
14 |
|
Total capacity of tanks |
7.041,99 m³ |
|
Cargo handling |
3x Pumps 1.500 m³/h |
|
Tank capacitues |
Fuel: 308,4 m³ |
|
ISM & commercial manager |
South End Tanker Management BV Aventurijn 218 3316 LB Dordrecht The Netherlands |
|
Registered owner |
Malia Shipping B.V. Care of South End Tanker Management BV Aventurijn 218 3316 LB Dordrecht The Netherlands |
|
Latest data adjustment |
10 November 2022 |
