Coastalwater 01
Vlissingen 15 October 2013



Name

COASTALWATER

Type

Chemical / Oil products tanker

IMO-number

9205158

Call sign

PEDM

Flag

The Netherlands

Port of registry

Papendrecht

GT

2.140 t

DWT

Summer: 3.731 t

NT

956 t

Displacement

Summer: 5.013 t

Light ship

1.264,65 t

Length

91,29 m overall

86,70 m between perpendiculars

Breadth

12,00 m extreme

Draught

Summer: 5,26 m

Winter: 4,15 m

Air draft

21,50 m

Keel to masthead

24,00 m

Foreship to bridge

76,35 m

Aft ship to bridge

16,00 m

Depth

6,80 m moulded

Speed

11,5 knots

Built

2000

Keel laid

20.11.1998

Date of completion

02.09.2000

Builder

Breko Shipbuilding & Repair
Papendrecht
The Netherlands

Hull material

Steel

Hull type

Double hull

Main engine

1x ABC 8 MDZC diesel engine - 1.768kW / 2.399 hp

Builder: Anglo Belgian Corporation N.V.

Wiedauwkaai 43
9000 Gent
Belgium

Propellers

1x CPP

Number of cargo tanks

10 - Marineline coating

Tank capacity

100%: 3.508,16 m³

98%: 3.438 m³

95%: 3.332,76 m³

Slop tanks

36 m³

Manifolds

Foreship to manifold: 29,56 m

Aft ship to manifold: 50,8 m

Bridge to manifold: 32,65 m

Manifold to main rail P&S: 3,00 m

Manifold to waterline in ballast: 5,46 m

Manifold to waterline in loaded condition: 3,34 m

Manifold to main deck: 1,70 m

Distance bow to mid-point manifold: 43,74 m

Distance stern to mid-point manifold: 47,57 m

Manager

Clearwater Group
Ohmweg 11
2952 BD Alblasserdam
The Netherlands

Operator

Clearwater Group

Owner

Coastalwater Shipping Company CV
Alblasserdam
The Netherlands

Last update

21.04.2013
