| Westerschelde 28 April 2019 |
 |
 |
 |
 |
|||
| Antwerpen 24/04/13 | Westerschelde 08/06/20 | Westerschelde 01/12/20 | Westerschelde 11/05/18 | |||
|
Name |
SEAMARLIN |
|
Type |
Oil Tanker - Suitable for carriage of various oil products |
|
IMO-number |
9380489 |
|
Call sign |
DDSL |
|
Flag |
Germany |
|
Port of registry |
Bremen |
|
GT |
26.548 t |
|
DWT |
40.549 t |
|
NT |
10.304 t |
|
Length |
188,18 m overall 181,56 m registered |
|
Breadth |
32,20 m registered |
|
Draught |
11,00 m |
|
Keel to mast end |
44,60 m |
|
Forecastle |
13,56 m |
|
Depth |
17,05 m moulded |
|
Speed |
16,5 knots |
|
Built |
2007 |
|
Keel laid |
21/11/2006 |
|
Launch date |
31/03/2007 |
|
Date of completion |
17/07/2007 |
|
Builder |
Lindenau GmbH Schiffswerft & Maschinenfabrik Christianspries 30 24159 Kiel Federal Republic of Germany |
|
Yard number |
S275 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double hull Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
10 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN-B&W 8L58/64CD - 4 stroke 8 cylinder 580 x 640 mm combustion engine 11.200 kW / 15.228 hp at 428 rpm Year of Manufacture: 2007 Manufacturer: MAN Diesel & Turbo SE Stadtbachstr. 1 86153 Augsburg Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 116 rpm |
|
Boilers |
1x Steam boiler, exhaust gas heated - 12,0 bar Heating surface: 92,0 m² 1x Steam boiler, oil fired - 12,0 bar Heating surface: 170,0 m² Year of manufacture: 2007 Manufacturer: Alfa Laval Aalborg A/S Gasvaerksvej 24 9100 Aalborg Kingdom of Denmark |
|
Electric installations |
3x Plants each 400/230 V - 1.425 kVA 1x Plant 400 V - 1.700 kVA 1x Plant 400 V - 200 kVA 1x Plant 24 V - 170 Ah 1x Plant 24 V - 170 Ah 1x Plant 24 V - 170 Ah |
|
Shaft generator |
1x 1.700 kVA |
|
Generators |
3x Wärtsilä 6L20 main diesel generatorsets each 1.425 kVA |
|
Emergency generator |
1x MAN D2866TE diesel generatorset 200 kVA |
|
Batteries |
1x Battery for UPS navigation 170 Ah 2x Batteries for automation each 170 Ah 2x Batteries for start emergency engine each 170 Ah |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 30,0 bar 1x Receiver 1.000 litres - 8,0 bar |
|
Bow thruster |
1x Transverse thruster - 1.250 kW, forward |
|
Number of tanks |
10 + 2 slop tanks |
|
Cargo tank capacity |
Liquid: 42.984 m³ |
|
Number of pumps |
10x Cargo pumps each 600 m³/h |
|
Anchor equipment |
3x Anchors weight each 8.300 kg Chain length: 632,50 m Diameter: 70 mm |
|
Crew size |
29 |
|
ISM & commercial manager |
German Tanker Shipping GmbH & Co. KG Hans-Böckler-Str. 50 28217 Bremen Federal Republic of Germany |
|
Registered owner |
German Tanker Shipping GmbH & Co. KG Hans-Böckler-Str. 50 28217 Bremen Federal Republic of Germany |
|
Latest data adjustment |
12 August 2022 |
