| Westerschelde 10 May 2020 |
 |
| Westerschelde 10/05/20 |
|
Name |
SCARLET RAY |
|
Type |
Oil/Chemical carrier |
|
IMO-number |
9799654 |
|
Call sign |
D5KB3 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GRT |
12.162 t |
|
DWT |
19.974,03 t |
|
NRT |
6.258 t |
|
Length |
145,26 m overall |
|
Breadth |
24,20 m moulded |
|
Draught |
Summer: 9,78 m |
|
Moulded L x B x D |
139,00 x 24,20 x 13,20 m |
|
Registered L x B x D |
139,26 x 24,20 x 13,20 m |
|
Keel to mast end |
37,15 m |
|
Freeboard |
Summer: 3.448 mm |
|
Depth |
13,20 m moulder |
|
Speed |
Service: 14,0 knots Max: 16,0 knots |
|
Built |
2020 |
|
Keel laid |
21/12/2015 |
|
Launch date |
11/09/2019 |
|
Date of completion |
19/02/2020 |
|
Builder |
Kitanihon Ship Building Co. Ltd. Hachinohe Japan |
|
Yard number |
653 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Mitsubishi 5UEC45LSE-1 - 2 stroke single acting 5 cylinder 450 x 1.840 mm combustion engine 4.900 kW / 6.662 hp at 124,0 rpm Manufacturer: Akasaka Diesels Limited |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 390 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 0,90 MPa Evaporation: 16,12 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
4x Diesel generatorsets total 2.350 kVA |
|
Bow thruster |
1x 700 kW |
|
Number of tanks |
20 |
|
Cargo tank capacity |
Liquid: 22.413,16 m³ |
|
Number of pumps |
20x Cargo pumps each 250 m³/h |
|
Tank capacities |
Fuel oil: 1.118,15 m³ Fresh water: 402,89 m³ |
|
ISM & commercial manager |
Eastern Pacific Shipping Pte 38-01, Millenia Tower, 1, Temasek Avenue Singapore 039192 Republic of Singapore |
|
Registered owner |
1-Shipping LBR Limited Care of Eastern Pacific Shipping Pte Ltd. 38-01, Millenia Tower, 1, Temasek Avenue Singapore 039192 Republic of Singapore |
|
Latest data adjustment |
09 July 2022 |
