Kristiansund, Norway 08 June 2019 |
 |
| Kristiansund 08/06/19 |
|
Name |
FRI SKY |
|
Previous names |
1982 - 1989 Pionier 1989 - 2001 Pernille W 2001 - 2017 Atlantica Hav 2017 - 2018 Peak Antwerpen |
|
Type |
General cargo vessel |
|
IMO-number |
8215730 |
|
Call sign |
C6RS3 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
1.514 t registered |
|
DWT |
2.309 t |
|
NT |
774 t registered |
|
Lightship |
792,7 t |
|
Number of 20ft containers |
48 |
|
Length |
82,09 m overall 77,35 m registered |
|
Breadth |
11,38 m registered |
|
Draught |
Summer: 4,18 m |
|
Keel to top antenna |
20,00 m |
|
Air draft |
Min: 6,51 m Max: 17,40 m |
|
Forecastle |
6,55 m |
|
Poop |
12,60 m |
|
Depth |
5,40 m moulded |
|
Speed |
10,0 knots |
|
Built |
1982 |
|
Keel laid |
04/06/1982 |
|
Launch date |
18/09/1982 |
|
Date of completion |
10/1982 |
|
Builder |
Schiffswerft Hugo Peters Wewelsfleth Peters & Co. GmbH 25599 Wewelsfleth Federal Republic of Germany |
|
Yard number |
593 |
|
Hull material |
Steel |
|
Hull type |
Single hull Partly double bottom |
|
Watertight bulkheads |
4 |
|
Watertight compartments |
6 |
|
Continuous decks |
2 |
|
Main engine |
1x Deutz SBA8M528 - 4 stroke single acting 8 cylinder 220 x 280 mm combustion engine 645 kW at 703 rpm Year of manufacture: 1982 Manufacturer: Klöckner-Humboldt-Deutz AG 51057 Köln Federal Republic of Germany |
|
Propellers |
1x Solid propeller - aft at 277 rpm |
|
Boilers |
1x Steam boiler, oil fired Year of manufacture: 1982 |
|
Electric installations |
1x Plant 380/220 V - 285 kVA 1x Plant 380 V - 57 kVA |
|
Shaft generator |
1x 57 kVA |
|
Generators |
1x Diesel generatorset 75 kVA - 60 kW - 102 hp 1x Diesel generatorset 210 kVA - 168 kW - 284 hp 1x Diesel generatorset 65 kVA - 52 kW - 68 hp |
|
Compressed air receivers |
2x Receivers each 125 litres - 30,0 bar 1x Receiver 30 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster JASTRAM BU 20F 217PS - 132 kW, forward |
|
Number of holds |
1x 2 boxes 50,40 x 9,00 x 6,30 m |
|
Number of hatches |
1 50,00 x 6,30 m 8 pieces - size = 9,25 x 6,30 m |
|
Hatch type |
MacGregor Piggy back multi stack |
|
Cargo capacity |
Grain:2.916 m³ Bales: 2.911 m |
|
Max permitted loads |
Hatch cover: 1,5 t/m² Tanktop: 11,0 t/m² |
|
Hold ventilation |
6 Air-changes/hours |
|
Tank capacities |
Fuel oil: 121 m³ Water ballast: 997 m³ Fresh water: 56,5 m³ |
|
Anchor equipment |
3x Anchors weight each 1.020 kg Chain length: 357,50 m |
|
Crew |
6 |
|
Manager |
Kopervik Ship Management |
|
Operator |
Wagle Chartering AS |
|
Registered owner |
Skagerak Shipping AS Hovedgaten 57 NO-4250 Kopervik Norway |
|
Previous shipping companies |
1982 Pioneer - Pionier Schiffahrtsges.Wolter & Co. 1989 Pernille W - K/S Saima 1992 Pernille W - H.H.Danship A/S 2001 Atlantic Hav - Atlantica Hav A/S 2013 Atlantic Hav - Skagerak Sg A/S 2017 Peak Antwerpen - Skagerak Sg A/S 2018 Fri Sky - Skagerak Sg A/S |
|
Special annotation |
Wheelhouse hydraulically lowerable |
|
Renamed |
2020 Ladoga Russia - Call sign: UBAV9 |
|
Latest data adjustment |
15 October 2019 |
