Westerschelde 16 August 2018 |
 |
| Westerschelde 16/08/18 |
|
Name |
SVENJA |
|
Type |
Multi-purpose dry cargo ship - Heavy lift - Equipped for carriage of containers - Strengthened for heavy cargo - Hatchcoverless |
|
IMO-number |
9458901 |
|
Call sign |
DIJA2 |
|
Flag |
Germany |
|
Port of registry |
Hamburg |
|
Previous flags |
Antigua & Barbuda, St. John’s - Call sign: V2FV7 |
|
GT |
15.199 t Suez: 15.670,10 t |
|
DWT |
Summer: 12.501t |
|
NT |
4.559 t Suez: 14.894,01 t Panama: 12.925 t |
|
Displacement |
Summer: 23.600 t |
|
Number of 20ft containers |
971 |
|
Length |
160,50 m overall 149,38 m between perpendiculars |
|
Breadth |
27,91 m extreme 27,50 m moulded |
|
Draught |
Summer: 9,01 m |
|
Freeboard |
Summer: 1.809 mm |
|
Depth |
13,80 m moulded |
|
Speed |
Max: 20,0 knots |
|
Built |
2010 |
|
Keel laid |
20/12/2007 |
|
Launch date |
25/09/2010 |
|
Date of completion |
09/12/2009 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. |
|
Yard number |
1279 |
|
Hull material |
Steel |
|
Hull type |
Single hull - Double bottom |
|
Continuous decks |
1 |
|
Main engine |
1X MAN B&W 9L58/64 CD - 4 stroke 9 cylinder combustion engine 12.610 kW/ 17.136 bhp at 428 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Thermal oil heater, oil fired 1x Thermal oil heater, exhaust heated |
|
Shaft generator |
1x 1.300 kW |
|
Generators |
3x Mitsubisi S6R2-MPTA main diesel generatorsets each 1.040 kW |
|
Emergency generator |
1x MAN D2866LXE20 diesel generatorset 200 kW |
|
Bow thruster |
2x Brunvoll FU-80-LCR-2250 - 1.200 kW forward 1x Brunvoll FU-63-LTC-1750 - 745 kW aft |
|
Number of holds |
1 107,10 x 17,00 x 13,50 m |
|
Cargo hold capacity |
18.470 m³ (with tweendeck) |
|
Free deck space |
128,50 x 27,50 m 3.427 m² |
|
Tank capacities |
Ballast water: 10.483 m³ Gas oil: 227 m³ HFO: 1.686 m³ Fresh water: 261 m³ |
|
Anchor equipment |
Length: 905,00 m Diameter: 62 mm |
|
Cargo gear |
2x Crane - SWL 1.000 t each Combinable up to 2.000 t SWL |
|
Crew size |
22 |
|
Technical manager |
SAL Ship Management UG (haftungsbeschränkt) & Co. KG |
|
Operator |
SAL Heavy Lift GmbH |
|
Registered owner |
SAL Heavy Lift GmbH |
|
Group |
Harren & Parther |
|
Latest data adjustment |
11 December 2018 |
