Plato 01

Westerschelde 24 May 2017



Name

PLATO

Type

General cargo ship - heavycargo

IMO-number

8822636

Call sign

8PRX

Flag

Barbados

Port of registry

Bridgetown

GT

1.990 t

DWT

Summer: 3.677 t

Winter: 3.568 t

NT

1.271 t

Length

88,15 m overall

83,20 m between perpendiculars

Breadth

14,18 m moulded

Draught

Summer: 5,01 m

Winter: 4,90 m

Keel to top antenna

Forward: 18,00 m

Aft: 29,50 m

Air draft

Max: 24,00 m

Freeboard

1.083 mm

Depth

6,35 m moulded

Speed

Service: 11,0 knots

Built

1989

Date of completion

30/09/1989

Builder

Pattje Shipyard B.V.
Waterhuizen
The Netherlands

Yard number

375

Hull material

Steel

Continuous decks

1

Main engine

1x MaK - 2 stroke 6 cylinder 320 x 450 mm combustion engine 1.180 kW / 1.603 hp at 450 rpm

Propellers

1x Screw propeller solid

Generators

2x Main diesel generatorsets 81 kVA - 65 kW - 88 hp

Emergency generator

1x Diesel generatorset 81 kVA - 65 kW - 211 hp

Bow thruster

236 kW

Number of holds

1

63,70 x 12,20 x 5,35 m

Cargo hold capacity

Bale: 4.455 m³ / 157.327 ft³

Grain: 4.469 m³ / 157.821 ft³

Number of hatches

2

Hatch 1: 26,00 x 10,20 m

Hatch 2: 26,00 x 10,20 m

Hatch type

Pontoon

Max permitted loads

Deck/hatch covers: 2,3 t/m²

Tanktop: 12,0 t/m²

Tank capacities

Water ballast: 1.189 m³

MGO: 188 m³

Owner

Wilson ASA
N-5835 Bergen
Norway

Registered owner

Wilson Ship Management AS

Latest data adjustment

25 August 2018
