Maestro Lion - IMO 9189665

Westerschelde 21 March 2018

Name

MAESTRO LION

Previous names

1999 - 10/2001 Swiftnes

10/2001 - 05/2010 UBC Salvador

Type

Bulk carrier - Handysize

IMO-number

9189665

Call sign

V7TU9

Flag

Marshall Islands

Port of registry

Majuro

Previous flags

Cyprus, Limassol

GT

19.743 t

DWT

Summer: 31.857 t

NT

10.718 t

Length

171,59 m overall

Breadth

27,00 m extreme

Draught

10,00 m

Forecastle

11,77 m

Poop

8,67 m

Depth

14,80 m

Speed

Max: 15,5 knots

Built

1999

Keel laid

01/12/1998

Launch date

06/02/1999

Delivery date

05/04/1999

Builder

Saiki Heavy Industries
Saiki
Japan

Hull material

Shipbuilding steel (higher tensile)

Hull type

Single hull double bottom, continuous from peak to peak bulkhead

Watertight bulkheads

7

Continuous decks

1

Main engine

1x Kobe Hatsudoki 6 UEC 52 LA - 2 stroke 6 cylinder 520 x 1.600 mm diesel engine 7.060 kW at 133,0 rpm

Propellers

1x Fixed pitch propeller

Boilers

1x Steam boiler, oil fired / exhaust gas heated - 6,8 bar
Heating surface 14,0 m²
Heating surface 174,0 m²

Manufacturer: Osaka Boiler Mfg. Co., Ltd.

Electric installations

1x Plant 440/220 V - 600 kVA
1x Plant 440/220 V - 600 kVA
1x Plant 440 V - 313 kVA

Generators

2x Yanmar 6N18L-EV main generators each 550 kW / 600 kVA

Emergency generator

1x Caterpillar emergency generator 250 kW / 313 kVA

Compressed air receivers

2x Receivers each 4.800 litres - 25,0 bar

Number of holds

5

2+3+4 box shaped
Hold 1: 22,12 x 15,00 x 13,20 m
Hold 2: 27,65 x 22,86 x 13,20 m
Hold 3: 27,65 x 22,86 x 13,20 m
Hold 4: 27,65 x 22,86 x 13,20 m
Hold 5: 27,65 x 18,00 x 13,20 m

Cargo hold capacity

Grain - Bale

Hold 1: 214.124 - 209.363 ft³
Hold 2: 316.656 - 314.462 ft³
Hold 3: 316.603 - 313.918 ft³
Hold 4: 316.603 - 314.425 ft³
Hold 5: 316.603 - 300.604 ft³
Total: 1.474.593 - 1.452.772 ft³

Number of hatches

5

Hatch 1: 13,43 x 15,00 m
Hatch 2: 20,54 x 22,86 m
Hatch 3: 20,54 x 22,86 m
Hatch 4: 20,54 x 22,86 m
Hatch 5: 19,75 x 18,00 m

Hatch type

Nakata Mak hydraulic folding

Max permitted loads

Tanktop: 22,0 t/m²

Tank capacities

Fuel IFO 380: 1.396 m³ (at 96%)
MDO: 370 m³ (at 96%)
Freshwater: 213,9 m³
Ballast tanks: 10.430,31 m³

Anchor equipment

3x Anchors weight each 6.450 kg
Chain Length: 605;00 m

Cargo gear

4x Deck cranes - SWL 30,0 t each

Outreach: 10,50 m

Crew size

30

Manager

Maestro Shipmanagement Ltd.
Limassol
Cyprus

Owner

Maestro Shipping SA
Avenue du Guintzet 8
1700 Fribourg
Switzerland

Latest data adjustment

20 June 2018
