Terneuzen 21 August 2017 |
|
Name |
ESTIME |
|
Type |
Multi-purpose cargo ship |
|
IMO-number |
9479931 |
|
Call sign |
PCKL |
|
Flag |
The Netherlands |
|
Port of registry |
Harlingen |
|
GT |
2.984 t |
|
DWT |
4.925 t |
|
NT |
1.598 t |
|
Number of 20ft containers |
38 on deck |
|
Length |
89,95 m overall 84,94 m between perpendiculars |
|
Breadth |
14,04 m moulded |
|
Draught |
Summer: 6,23 m |
|
Freeboard |
1.332 mm |
|
Depth |
7,85 m moulded |
|
Speed |
11,5 knots |
|
Built |
2011 |
|
Launch date |
16/04/2011 |
|
Delivery date |
19/08/2011 |
|
Builder |
Chowgule and Company PVT. Limited |
|
Yard number |
195 |
|
Hull material |
Steel |
|
Watertight compartments |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm diesel engine 1.980 kW / 2.690 kW at 750 rpm Built: 04/01/2009 Builder: Caterpillar Motoren Guangdong Co. Ltd. (CMG), Gaungdong - China |
|
Propellers |
1x Screw propeller controllable pitch - aft at 158 rpm |
|
Shaft generator |
1x 390 kVA - 312 kW |
|
Generators |
1x Main diesel generatorset 210 kVA - 168 kW - 245 hp |
|
Emergency generator |
1x Diesel generatorset 210 kVA - 168 kW - 245 hp |
|
Bow thruster |
1x 250 kW |
|
Number of holds |
1 62,30 x 11,70 x 8,12 m |
|
Cargo hold capacity |
204.825 ft³ / 5.800 m³ |
|
Tanktop area |
700 m² |
|
Max permitted loads |
Tanktop: 15,0 t/m² Hatch cover: 1,6 t/m² |
|
Tank capacities |
HFO 380: 284 m³ Water ballast: 1.919 m³ Fresh water 50 m³ |
|
Manager |
JR Shipping B.V. |
|
Owner |
M.S. Estime Scheepvaartbedrijf N.V. |
|
Latest data adjustment |
26 February 2018 |
