Westerschelde 30 May 2018 |
 |
 |
|
| Westerschelde 30/05/18 | Westerschelde 21/07/17 |
|
Name |
FEHN POLLUX |
|
Previous names |
1996 - 1997 Saar Amsterdam 1997 - 2003 A.B. Amsterdam 2003 - 2007 AB Amsterdam 2007 - 2014 Fehn Heaven |
|
Type |
General cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo - Single decker |
|
IMO-number |
9135731 |
|
Call sign |
V2EI8 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John’s |
|
GT |
2.844 t |
|
DWT |
Summer: 4.211 incl. bulkheads |
|
NT |
1.568 t |
|
Number of 20ft containers |
In hold: 117 On deck: 104 Total: 221 |
|
Container capacity 14t |
156 |
|
Reefer plugs |
12 |
|
Length |
89,77 m overall 84,95 m between perpendiculars |
|
Breadth |
13,17 m extreme |
|
Draught |
5,67 m |
|
Air draft |
28,00 m basis full ballast |
|
Depth |
7,15 m |
|
Speed |
11,0 knots |
|
Built |
1996 |
|
Keel laid |
29/09/1995 |
|
Launch date |
20/07/1996 |
|
Date of completion |
01/12/1996 |
|
Builder casco |
Santierul Naval Galati S.A. Romania Yard number: 739 |
|
Builder completion |
B.V. Scheepswerf Damen Hoogezand The Netherlands Yard number: 909 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Movable bulkheads |
2x Movable, max. 3 compartments |
|
Continuous decks |
1 |
|
Main engine |
1x MWM Deutz SBV 9 M 628 - 4 stroke single acting 9 cylinder combustion engine 1.823 kW at 900 rpm |
|
Propellers |
1x Controllable pitch propeller - aft at 183 rpm |
|
Boilers |
1x Auxiliary boiler, oil/gas fired |
|
Shaft generator |
1x 336 kW |
|
Generators |
2x Main diesel generatorset each 136 kW |
|
Emergency generator |
1x Diesel generatorset 62 kW |
|
Bow thruster |
1x 300 kW |
|
Number of holds |
1x Boxshaped 62,49 x 11,00 x 8,43 m incl. bulkheads |
|
Cargo hold capacity |
Grain: 5.718 m³ |
|
Hold ventilation |
Elec. driven 6 air changes per hour |
|
Number of hatches |
1 62,50 x 10,10 m 10 steel pontoon hatches with 1 gantry crane |
|
Hatch cover type |
Coops & Nieborg |
|
Max. Permitted loads |
Main deck: 1,6 t/m² Tank top: 18,0 t/m² |
|
Tank capacities |
Ballast: 1.626,99 m³ IFO: 235,58 m³ MGO: 37,29 m³ Fresh water: 41,44 m³ |
|
Anchor equipment |
Length: 330,00 m Diameter: 36 mm |
|
Cargo gear |
Gearless |
|
Crew size |
8 |
|
Manager |
Fehn Ship Management GmbH & Co. KG Hafenstraße 15 26789 Lee Germany |
|
Registered owner |
Ems Chartering GmbH & Co. KG Hafenstraße 15 26789 Lee Germany |
|
Group |
EMS-Fehn-Group |
|
Latest data adjustment |
23 February 2020 |
