FederaL Kumano 01

Westerschelde 02 November 2014



Name

FEDERAL KUMANO

Type

Dry bulk carrier - Heavy dry bulk cargo carriage - Grain carriage

IMO-number

9244257

Call sign

V7RF4

Flag

Marshall Islands

Port of registry

Majuro

Previous flags

Hong Kong - China, Hong Kong - Call sign: VRYL4

GT

20.661 t registered

DWT

Summer: 36.489 t

Winter: 35.517 t

NT

12.020 t registered

Panama: 17.263 t

Suez: 18.942 t

Length

199,99 m overall

191,00 m between perpendiculars

Breadth

23,76 m extreme

Draught

10,75 m

Depth

14,85 m

Speed

14,0 knots

Built

2003

Keel laid

10.12.2001

Launch date

11.12.2002

Date of completion

20.02.2003

Builder

Oshima Shipbuilding Co., Ltd.
1605-1 Oshima-cho
857-2494 Saikai City
Japan

Yard number

10321

Hull material

Steel

Bulkheads

Transverse: 8

Main engine

1x MAN B&W 6S46MC-C - 2 stroke 6 cylinder diesel engine 10.710 hp at 129 rpm

Propellers

1x mono-block propeller
Builder: Nakashima Propeller Co., Ltd.

Boilers

Auxiliary boiler, composite GCS-22ST

Builder: Aalborg Industries A/S

Generators

3x Daihatsu 5DK-20 diesel generatorsets each 740 kW

Builder: Daihatsu Diesel Mfg. Co., Ltd.

Emergency generator

1x Deutz BF6L913 diesel generatorset

Bow thruster

Yes

Number of holds

6

Hold 1: 26,00 x 8,24 / 19,80 m

Hold 2: 26,80 x 19,80 / 19,80 m

Hold 3: 25,00 x 19,80 / 19,80 m

Hold 4: 21,40 x 19,80 / 19,80 m

Hold 5: 26,00 x 19,80 / 19,80 m

Hold 6: 26,00 x 19,80 / 9,90 m

Hold capacity

Grain / Bale

Hold 1: 7.109 m³ / 6.866 m³

Hold 2: 7.990 m³ / 7.663 m³

Hold 3: 7.499 m³ / 7.166 m³

Hold 4: 6.394 m³ / 6.089 m³

Hold 5: 7.759 m³ / 7.412 m³

Hold 6: 7.333 m³ / 7.093 m³

Total: 44.084 m³ / 42.289 m³

Number of hatches

Hatch 1: 17,10 x 13,20 m

Hatch 2: 19,80 x 13,20 m

Hatch 3: 19,80 x 13,20 m

Hatch 4: 13,50 x 13,20 m

Hatch 5: 19,80 x 13,20 m

Hatch 6: 18,00 x 13,20 m

Hatch cover type

Folding hydraulic

Max. permitted loads

Tanktop:

Hold 1: 22,0 t/m²

Hold 2: 20,5 t/m²

Hold 3: 21,0 t/m²

Hold 4: 24,5 t/m²

Hold 5: 21,0 t/m²

Hold 6: 22,0 t/m²

Tank capacities

IFO: 1.401 m³

MGO: 436 m³

Ballast: 19.730,5 m³

Anchor equipment

Length: 605,00 m

Diameter: 62 mm

Cargo gear

3x Electro hydraulic cranes - SWL 30, t each

Manager

Anglo-Eastern Ship Management Limited

Operator

Fednav Ltd.
Headquarters:

1000 de La Gauchetière Street West, Suite 3500
Montreal
Quebec H3B 4W5
Canada

Previous owners

Baffin Investments Ltd.

Latest data adjustment

22 August 2016
