Antwerpen 16 May 2014 |
 |
| Antwerpen 16/05/14 |
|
Name |
TUPERNA |
|
Previous names |
2006 - 05.2007 Tuperna 05/2007 - 01/2009 Anette Scan 01/2009 - 05/2009 Tuperna 05/2009 - 03/2010 Southern Phoenix |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo Tweendecker |
|
IMO-number |
9375874 |
|
Call sign |
V2BT7 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
2.588 t |
|
DWT |
3.345 t |
|
NT |
1.376 t |
|
Number of 20ft containers |
167 |
|
Length |
86,58 m overall 81,07 m registered |
|
Breadth |
12,80 m registered |
|
Draught |
5,54 m |
|
Air draft |
25,90 m ballast |
|
Depth |
7,10 m moulded |
|
Speed |
12,1 knots |
|
Built |
2006 |
|
Keel laid |
29/04/1998 |
|
Launch date |
30/06/2006 |
|
Date of completion |
09/12/2006 |
|
Builder |
Slovenske Lodenice Komarno a.s. Rolnickej Skoly 1519 945 01 Komarno Slovak Republic |
|
Yard number |
1910 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
8 |
|
Movable bulkhead |
2x Movable units various positions |
|
Continuous decks |
1 |
|
Main diesel engine |
1x MaK 6M25 - 4 stroke 6 cylinder 255 x 400 mm combustion engine 1.980 kW at 750 rpm Year of manufacture: 2006 Caterpillar Motoren GmbH & Co. KG Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Main electric motor |
1x Leroy-Somer - 80 KW at 1.500 rpm Manufacturer: Leroy-Somer S.A. Boulevard Marcellin Leroy 16000 Angouleme Republic of France |
|
Propellers |
1x Controllable pitch propeller - aft at 219 rpm |
|
Boilers |
1x Water heater, oil fired - 5,0 bar |
|
Electric installations |
2x Plants each 400 V - 370 kVA 1x Plant 400 V - 470 kVA 1x Plant 400 V - 150 kVA |
|
Shaft generator |
1x 470 kVA |
|
Generators |
2x Scania main diesel generatorsets each 370 kVA |
|
Emergency generator |
1x Diesel generatorset 150 kVA |
|
Harbour generator |
47 kW |
|
Compressed air receivers |
2x Receivers each 250 litres- 30,0 bar 1x Receiver 10 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster 185 kW, forward |
|
Hold dimension |
Hold: 56,50 x 10,20 x 8,10 m Tween: 56,50 x 10,20 m Adjustable height: Hold bottom to lower position: 4,31m Hold bottom to upper position: 5,44 m Lower position twd to hatch coaming: 3,31 m Upper position twd to hatch coaming: 2,19 m |
|
Hold capacity |
163.000 ft³ / 4.615 m³ |
|
Hatch cover type |
Kvaerner type |
|
Max permitted loads |
Tanktop: 20,0 t/m² Tween deck: 2,50 t/m² Deck: 1,60 t/m² |
|
Anchor equipment |
3x Anchors weight each 2.100 kg Chain length: 440,00 m Diameter: 36 mm |
|
Cargo gear |
2x NMF cranes - SWL 35,0 t each |
|
Crew size |
12 |
|
Manager |
Reederei Erwin Strahlmann e.K. Schleusenstr. 10 25541 Brunsbüttel Federal Republic of Germany |
|
Operator |
R.E.S. Chartering GmbH Katharinenstraße 7-9 20457 Hamburg Germany |
|
Registered owner |
Reederei Erwin Strahlmann e.K. Schleusenstr. 10 25541 Brunsbüttel Federal Republic of Germany |
|
Renamed |
05/2021 Karoline Antigua and Barbuda, St. John's - Call sign: V2BT7 Owner: MS "KAROLINE" Jens u. Waller GmbH & Co. KG Manager: Reederei Jens & Waller GmbH & Co. KG |
|
Latest data adjustment |
03 June 2021 |
