Antwerpen 14 July 2014 |
 |
 |
 |
 |
 |
||||
| Antwerpen 14/07/14 | Antwerpen 14/07/14 | Merksem 17/01/15 | Westerschelde 03/07/14 | Westerschelde 04/08/18 |
|
Name |
LEIRIA |
|
Previous names |
2003 Launch as: Leira |
|
Type |
Multi-Purpose dry cargo ship - Equipped for Carriage of Containers - Strengthened for heavy cargo Singledecker - Boxlike |
|
IMO-number |
9248370 |
|
Call sign |
V2QN3 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
Saint John's |
|
Previous flag |
2003 Portugal, Madeira - Call sign: CQTH 2012 Antigua & Barbuda, Saint John's - Call sign: V2QN3 Cyprus, Limassol- Call sign: 5BYU3 |
|
GT |
1.921 t |
|
DWT |
Summer: 2.652 t |
|
DWCC |
Summer: 2.550 t Winter: 2.450 tr |
|
NT |
1.123 t |
|
Length |
89,70 m overall 86,66 m between perpendiculars |
|
Breadth |
11,32 m |
|
Draught |
Max: 4,13 m 3,10 m in ballast |
|
Air draft |
6,00 m in ballast |
|
Freeboard |
1.200 mm |
|
Depth |
5,35 m |
|
Speed |
10,0 knots |
|
Built |
2003 |
|
Keel laid |
19/04/2001 |
|
Launch date |
03/10/2003 |
|
Date of completion |
25/07/2003 |
|
Builder |
Estaleiros Navais Do Mondego S.A. |
|
Yard number |
CT.0245 |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Movable bulkhead |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x Deutz SBV 6M628 - 4 stroke single acting 6 cylinder 240 x 280 mm combustion engine 1.171 kW / 1.591 hp at 900 rpm Start type: Compressed air Built: 2001 Builder: Deutz AG, Mannheim - Germany |
|
Propellers |
1x Screw propeller solid - aft at 296 rpm |
|
Electric installations |
380/220 Volt - 50 Hz |
|
Generators |
3x Main diesel generatorsets each 169 kVA - 135 kW - 155 hp |
|
Emergency generator |
1x Diesel generatorset 38 kVA - 30 kW - 35 hp |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Schottel 165 KW, forward |
|
Number of holds |
1 61,20 x 9,30 x 6,90 m |
|
Hold capacity |
Grain/ bales: 3.928 m³ / 138.000 ft³ with 2 bulkhead |
|
Number of hatches |
1 61,20 x 9,30 m |
|
Hatch type |
Pontoon |
|
Strength |
Tanktop: 14 t/m² |
|
Tank capacities |
Fuel oil: 117,48 m³ Ballast water: 1.453 m³ |
|
Anchor equipment |
3x Length: 412,50 m - 1.590 kg |
|
Lifting equipment |
1x Gantry crane |
|
Manager |
Baltnautic Shipmanagement Ltd. |
|
Registered owner |
Caribbean Shipping Limited St. John's Antigua & Barbuda |
|
Previous owners & names |
2003: Leira - Naveiro Transportes Maritimos Lda. (Naveiro Transportes Maritimos S.A.), Funchal - Madeira / Portugal |
|
Latest data adjustment |
06 January 2015 |
