Westerschelde 26 October 2019 |
 |
 |
 |
||
| Antwerpen 15/07/14 | Antwerpen 24/07/14 | Antwerpen 24/07/14 |
|
Name |
ITALIA REEFER |
|
Previous names |
1992 - 07/2014 Chiquita Italia |
|
Type |
General and refrigerated cargo vessel |
|
IMO-number |
9030137 |
|
Call sign |
CGKD5 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
13.049 t |
|
DWT |
Summer: 12.273 t Winter: 11.700 t |
|
NT |
5.353 t Panama: 10.877 t Suez: 10.958,59 t |
|
Number of 20ft containers |
332 |
|
Number of 40ft containers |
170 |
|
Reefer plugs |
147 |
|
Length |
158,13 m overall 146,60 m between perpendiculars |
|
Breadth |
24,40 m |
|
Draught |
Summer: 10,02 m Winter: 9,81 m |
|
Keel to mast end |
45,58 m |
|
Freeboard |
2.807 mm |
|
Depth |
15,70 m |
|
Speed |
Service: 21,5 knots |
|
Built |
1992 |
|
Keel laid |
01/02/1992 |
|
Launch date |
15/04/1992 |
|
Date of completion |
21/08/1992 |
|
Builder |
Danyard A/S Frederikshavn Denmark |
|
Yard number |
712 |
|
Hull material |
Steel |
|
Watertight compartments |
7 |
|
Continuous decks |
6 |
|
Main engine |
1x Kawasaki/Man-B&W 8S60MC - 2 stroke single acting 8 cylinder 600 x 2.292 mm combustion engine 15.218 kW / 20.677 hp at 102,0 rpm Built: 1992 Manufacturer: Kawasaki Heavy Industries Co., Ltd., Kobe - Japan |
|
Propellers |
1x Screw propeller solid - aft at 102 rpm |
|
Boilers |
1x CHR Aalborg Boilers 980,00 m² - 10,0 bar 1x CHM Aalborg Boilers 48,00 m² - 10,0 bar |
|
Generators |
2x Main diesel generatorsets each 2.000 kVA - 1.600 kW - 2174 hp 2x Main diesel generatorsets each 1.250 kVA - 1.000 kW - 1.359 hp |
|
Emergency generator |
1x Diesel generatorset 195 kVA - 156 kW |
|
Bow thruster |
1.000 kW |
|
Number of holds |
4 |
|
Total capacity of holds |
18.275 m³ / 645.586 ft³ |
|
Number of hatches |
4 |
|
Number of compartments |
18 |
|
Floorspace |
7.565 m² |
|
Pallets |
8.611 |
|
Cooling sections |
7 |
|
Number of tanks |
Fuel oil: 12 Ballast: 11 Lubricating oil: 9 Fresh water: 5 Diesel oil: 4 Slop: 2 Chain1 Sludge: 1 Thermal oil: 1 Waste water: 1 |
|
Tank capacities 100 % |
Fresh water: 352 m³ Fuel oil: 1.986 m³ Gas oil: 95 m³ Tank ballast: 2.598 m³ |
|
Cargo gear |
2x Cranes x 20,0 t or 1x 40,0 t in twin 2x Cranes x 36,0 t or 8,0 t in low speed modus |
|
Manager |
Seatrade Reefer Chartering N.V. C/o Branch office Atlantic House (4th floor) Noorderlaan 147 2030 Antwerp Belgium |
|
Operator |
Seatrade |
|
Registered owner |
Italia Shipping Corporation |
|
Renamed |
2019 Italia Stream Bahamas, Nassau - Call sign: C6KD5 Owner: Italia Stream Shipping Co., Ltd. Manager: Seatrade Groningen BV - The Netherlands |
|
Latest data adjustment |
16 August 2021 |
