Westerschelde 03 October 2014 |
 |
 |
 |
 |
|||
| Antwerpen 30/05/14 | Westerschelde 02/02/17 | Westerschelde 02/02/17 | Westerschelde 14/12/18 |
|
Name |
SCOT VENTURE |
|
Type |
General cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo Box shaped single decker |
|
IMO-number |
9243928 |
|
Call sign |
VSSO2 |
|
Flag |
United Kingdom |
|
Port of registry |
Inverness |
|
GT |
2.602 t |
|
DWT |
Summer: 3.262 t |
|
DWCC |
3.050 t |
|
NT |
1.395 t |
|
Number of 20ft containers |
On deck: 60 In hold: 102 Total: 162 |
|
Number of 40ft containers |
On deck: 20 In hold: 48 Total: 68 |
|
Length |
89,98 m overall 84,99 m registered |
|
Breadth |
13,75 m registered |
|
Draught |
Summer: 4,92 m |
|
Air draft |
21,70 m in ballast |
|
Depth |
6,25 m moulded |
|
Speed |
13,5 knots |
|
Built |
2002 |
|
Keel laid |
26/06/1998 |
|
Launch date |
22/03/2002 |
|
Date of completion |
26/04/2002 |
|
Builder |
Tille Scheepsbouw Kootstertille B.V. Balkwar 10 9288 ZG Kootstertille The Netherlands |
|
Yard number |
340 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
4 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 6L26A - 4 stroke 6 cylinder 260 x 320 mm combustion engine 1.950 kW / 2.650 hp at 1.000 rpm Year of manufacture: 2002 Manufacturer: Wärtsilä Diesel AB, Trollhättan - Sweden |
|
Propellers |
1x Controllable pitch propeller - aft at 224 rpm |
|
Electric installations |
2x Plants each 380/ 220 V - 183 kVA 1x Plant380 V - 530 kVA |
|
Shaft generator |
1x 348 kW |
|
Generators |
2x Cummins main diesel generatorsets each 183 kVA / 147 kW |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster 305 kW, forward |
|
Number of holds |
1 61,88 x 10,80 x 7,92 m |
|
Hold capacity |
Grain / bales: 4.870 m³ / 179.834 ft³ |
|
Timber-fitted capacity |
5.000 m³ |
|
Number of hatches |
1 61,88 x 10,80 m |
|
Max. permitted loads |
Tank top: 15,0 t/m² Hatch covers: 1,60 t-m² |
|
Tank capacities |
Fuel oil: 290 m³ Water ballast: 1.557 m³ |
|
Anchor equipment |
3x Anchors weight each 1.920 kg Chain Length: 440,00 m Diameter: 34 mm |
|
Cargo gear |
1x Gantry crane - SWL 14,0 t |
|
Manager |
Intrada Ships Management Ltd. Riverside Estate, Sir Thomas Longley Rd Rochester ME2 4DP United Kingdom |
|
Registered owner |
Scot Venture Shipping Ltd. 41, Culduthel Road Inverness, IV2 4AT Highland United Kingdom |
|
Head Office |
Scotline Ltd. 75 Main Road Gidea Park Romford Essex, RM2 5EL United Kingdom |
|
Latest data adjustment |
17 December 2021 |
