Name
|
FANJA
|
|
Previous names
|
2000 Launch as: CEC Courage
2000 - 09/2001 Shanghai Star
09/2001 - 06/2002 CEC Courage
06/2002 - 12/2002 Shanghai Star
12/2002 - 04/2008 CEC Courage
|
|
Type
|
General multi-purpose cargo ship - Heavy lift ship
|
|
IMO-number
|
9235115
|
|
Call sign
|
3ERF2
|
|
Flag
|
Republic of Panama
|
|
Port of registry
|
Panama City
|
|
GT
|
6.714 t
|
|
DWT
|
Summer: 8.733 t
|
|
NT
|
2.893 t
|
|
Number of 20ft containers
|
In hold: 220
On deck: 430
Total: 650
|
|
Reefer capacity
|
116
|
|
Length
|
100,48 m overall
|
|
Breadth
|
20,82 m
|
|
Draught
|
8,20 m
|
|
Depth
|
11,10 m
|
|
Speed
|
Max: 16,3 knots
|
|
Built
|
2000
|
|
Date of completion
|
18/10/2000
|
|
Builder
|
Hudong Zhonghua Shipbuilding Group
Shanghai
China
|
|
Yard number
|
423
|
|
Hull material
|
Steel
|
|
Hull type
|
Single hull
|
|
Bulkheads
|
3
|
|
Number of decks
|
1
|
|
Main engine
|
1x Wärtsilä 8L46B - 8 cylinder combustion engine 7.800 kW / 10.605 hp
|
|
Propellers
|
1x Controllable pitch propeller
4 bladces
|
|
Generators
|
3x Main diesel generatorsets each 530 kW
|
|
Emergency generator
|
1x Diesel generatorset 108 kW
|
|
Bow thruster
|
1x 500 kW
|
|
Number of holds
|
1
|
|
Cargo hold capacity
|
Grain: 10.632 m³
|
|
Number of hatches
|
1
64,40 x 15,30 m
|
|
Tank capacities
|
Fuel oil: 882,1 m³
Fresh water: 90,3 m³
Water ballast: 3.005,0 m³
|
|
Cargo gear
|
2x Deck cranes - SWL 150 t each
|
|
Lifting equipment
|
1x Crane - SWL 1,5 t
2x Cranes - SWL 2,0 t each
|
|
Crew size
|
18
|
|
Commercial manager
|
Oman Shipmanagement
Dohat Al Adab Street, bldg no. A75 (OSC)
Al Khuwair
118, Al Harthy Complex
Madinat Sultan Qaboos
Sultanate of Oman
|
|
ISM manager
|
J. Poulsen Shipping A/S
Korsor
Denmark
|
|
Owner
|
Fanja Maritime Transportation - United Kingdom
c/o Oman Ship Management SAOC
Muscat
Oman
|
|
Scrapped
|
2017 as Fan - Alang - India
Flag: Comoros
|
|
Latest data adjustment
|
30 December 2023
|
