| Zeebrugge 24 January 2009 |
|
Name |
WESTERN TRADER |
|
Previous name |
1991 - 1992 Western Trader |
|
Type |
General cargo ship - Strengthened for heavy cargo, Equipped for carriage of containers |
|
IMO-number |
9031416 |
|
Call sign |
V2IO |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
4.164 t |
|
DWT |
4.635 t |
|
NT |
1.965 t |
|
Number of 20ft containers |
381 |
|
Reefer Plugs |
42 |
|
Length |
111,05 m overall |
|
Breadth |
16,07 m overall |
|
Draught |
Summer: 5,972 m |
|
Forecastle |
6,08 m |
|
Poop |
9,90 m |
|
Freeboard |
2.440 mm |
|
Depth |
8,40 m moulded |
|
Speed |
14,5 knots |
|
Built |
1991 |
|
Date of order |
01.02.1991 |
|
Keel laid |
16.04.1991 |
|
Launch date |
02.11.1991 |
|
Date of completion |
12.1991 |
|
Builder |
Schiffswerft Hugo Peters Wewelsfleth Peters & Co. GmbH |
|
Yard number |
640 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull |
|
Watertight bulkheads |
6 |
|
Continuous decks |
2 |
|
Main engine |
1x MAK 9 M 453 C - 4 stroke single acting 9 cylinder 320 x 420 mm diesel engine - 3.300 kW |
|
Number of screws |
1x Controllable pitch propeller - aft |
|
Boilers |
1x Water heater, oil fired - 4,0 bar |
|
Electric installations |
1x 400/220 V - 575 kVA |
|
Shaft generator |
1x 625 kVA |
|
Generators |
2x Main diesel generatorsets each 287,5 kVA |
|
Emergency generator |
1x Diesel generatorset 75 kVA |
|
Bow thruster |
1x Transverse thruster JASTRAM - forward |
|
Cargo capacity |
Bale: 7.124 m³ |
|
Largest hatch |
Length: 25,20 m |
|
Anchor equipment |
3x Anchors weight each 3.060 kg |
|
Compressed air receivers |
2x Receivers each 500 - 30,0 bar |
|
Crew |
11 |
|
Manager |
Hermann Bus Gmbh & Cie KG |
|
Operator |
Feederlink |
|
Owner |
Hermann Buss KG MS "WESTERN TRADER" GmbH & Co. |
