| Brugge, Belgium 02 August 2011 |
 |
 |
|
| Brugge 02/08/11 | Brugge 02/08/11 |
|
Name |
NAJADE |
|
Type |
Multi-purpose dry cargo carrier |
|
IMO-number |
9467213 |
|
Call sign |
PBZC |
|
Flag |
The Netherlands |
|
Port of registry |
Harlingen |
|
GT |
2.862 t |
|
DWT |
3.652 t |
|
NT |
1.295 t |
|
Number of 20ft containers |
44 |
|
Length |
94,70 m overall 91,30 m between perpendiculars |
|
Breadth |
13,44 m |
|
Draught |
Summer: 5,30 m |
|
Air draft |
Ballast: 23,00 m |
|
Depth |
7,80 m |
|
Speed |
13,6 knots |
|
Built |
2011 |
|
Launch date |
24/09/2010 |
|
Delivery |
04/01/2011 |
|
Builder |
Hexing Shipbuilding & Repair Yard Wenling China |
|
Yard number |
06-005 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Moveable bulkhead |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 155 x 400 mm combustion engine 2.010 kW / 2.731 hp at 751 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x CHR Aalborg Industries 74,90 m² - 10,0 bar 1x CHO Aalborg Industries 122,00 m² - 10,0 bar |
|
Generatorsets |
2x Main diesel generator sets each 390 kVA - 312 kW - 247 hp |
|
Bow thruster |
1x 250 kW |
|
Holds |
1x Box shaped, steel floored 61,60 x 11,20 x 8,34 m |
|
Cargo capacity |
Bale & grain: 5.510,1 m³ / 194.500 ft³ Timber: 4.800 m³ |
|
Number of hatches |
1 61,60 x 11,20 m |
|
Tank capacities |
Fuel: 211,2 m³ |
|
Crew |
7 |
|
Manager |
Wijnne & Barends' Cargadoors- en Agentuurkantoren B.V. Handelskade Oost 5, 9934 AR Delfzijl The Netherlands |
|
Owner |
Swem CV- M. Swityn, kLoppersum - The Netherlands Care of Wijnne & Barends Cargadoors - en Agentuurkantoren BV Handelskade Oost 5 9934 AR Delfzijl The Netherlands |
|
Renamed |
08/2022 Katariina Antigua & Barbuda, St. John's - Call sign: V2QZ9 Owner & manager: Hansa Ship Management OU, Tallinn (Reval) - Estonia |
|
Latest data adjustment |
28 September 2022 |
