| Antwerpen 20 April 2012 |
 |
| Antwerpen 20/04/12 |
|
Name |
CHRISTOPH M |
|
Previous names |
Hermann W Marlene |
|
Type |
Box-shaped singledecker - strengthened for heavy cargo |
|
IMO-number |
9508639 |
|
Call sign |
9HA2424 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
3.556 t Suez: 3.614,12 t |
|
DWT |
4.763,89 t |
|
NT |
1.535 t Suez: 2.836,87 t |
|
Displacement |
6.617,72 t |
|
Light ship |
1.872,98 t |
|
Length |
89,97 m overall 84,95 m between perpendiculars |
|
Breadth |
15,40 m |
|
Draught |
5,60 m |
|
Distance bow to bridge |
77,95 m |
|
Distance aft to bridge |
12,00 m |
|
Height above keel |
26,40 m |
|
Depth to main deck |
7,60 m |
|
Speed |
11,5 knots- full load |
|
Built |
2010 |
|
Builder |
Weihal Donghai Shipyard Co. Ltd. |
|
Yard number |
DHZ-07-15 |
|
Bulkheads |
2x movable bulkheads |
|
Main engine |
1x ZJMD MAM B&W 8L28/3A - 1.960 kW |
|
Propeller |
1x Fixed propeller - left hand effect |
|
Generators |
2x Henan Diesel MWM TBD 234 V12 diesel engines coupled with 2 generator each 350 kW 450 Volt, 50Hz |
|
Emergency generator |
Cummins 6CT18 3D(M) diesel generatorset 110 kW 450 Volt, 50Hz |
|
Bow thruster |
1x 250 kW |
|
Number of holds |
1 54,40 (53,30) x 12,60 x 8,40 m |
|
Number of hatches |
1 54,60 x 12,60 m |
|
Cargo capacity |
Bales & Grain: 5.777 m³ / 204.076 ft³ |
|
Load capacity |
Tanktop: 15,0 t/m² Tweendeck: 2,5 t/m² Weather deck: 1,75 t/m² |
|
Pumps |
Fire pump: 65 m³/h Ballast pump: 200 m³/h Stripping ejector: 25 m³/h |
|
Tank capacities |
Water ballast: 2975.9 m³ Fresh water: 38,7 m³ Fuel oil: 231,5 m³ (100%) Diesel oil: 84,9 m³ (100%) |
|
Manager |
Team Shipmanagement Bremerhaven Germany |
|
Operator |
Pool Carriers |
|
Owner |
Team Shipmanagement Bremerhaven Germany |
