Vlissingen 27 October 2016 |
 |
 |
 |
 |
 |
 |
|||||
| Vlissingen 27/10/16 | Vlissingen 27/10/16 | Vlis 27/10/16 | Zeebrugge 25/07/13 | Zeebrugge 25/07/13 | Westerschlde 10/03/16 | |||||
|
Name |
JBU MAAS |
|
Type |
Liquefied gas tanker |
|
IMO-number |
9366940 |
|
Call sign |
3EQY6 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
9.735 t |
|
DWT |
Summer: 11.787 t |
|
NT |
2.920 t |
|
Length |
126,70 m overall 119,30 m between perpendiculars |
|
Breadth |
20,43 m |
|
Draught |
Summer: 9,30 m |
|
Moulded L x B x D |
119,30 x 20,40 x 11,80 m |
|
Registered L x B x D |
120,55 x 20,40 x 11,80 m |
|
Freeboard |
2.210 mm |
|
Depth |
11,80 m moulded |
|
Speed |
Max: 16,0 knots |
|
Built |
2008 |
|
Keel laid |
26/06/2007 |
|
Date of completion |
18/08/2008 |
|
Builder |
Sekwang Heavy Industries Co., Ltd. Ulsan South Korea |
|
Yard number |
1157 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x MAN-B&W 6L48/60B - 4 stroke single acting 6 cylinder 480 x 600 mm combustion engine 7.200 kW / 9.783 hp at 500 rpm Build: 20/05/2007 Builder: MAN B&W Diesel AG, Augsburg - Germany |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 480 mm |
|
Propellers |
1x Screw propeller controllable pitch - aft at 120,0 rpm |
|
Boilers |
1x CHO Miura 30,60 m² - 10,0 bar, 1x CHR Miura 118,00 m² - 10,0 bar |
|
Generators |
3x Main diesel generatorsets 950 kVA - 760 kW - 1.196 hp |
|
Emergency generators |
1x Diesel generatorset 150 kVA - 120 kW - 163 hp |
|
Bow thruster |
590 kW |
|
Number of gas tanks |
2 |
|
Cargo capacity |
Liquid: 10.115 m³ |
|
Minimum temperature |
-104°C |
|
Tank capacities |
Fuel oil: 1.129 m³ Fresh water: 149 m³ Water ballast: 2.803 m³ |
|
Crew |
21 |
|
Manager |
Selandia Ship Management (Singapore) Pte. Ltd. 30 Old Toh Tuck Road #05-04 Singapore 597654 Republic of Singapore |
|
Owner |
Siva Shipping Oslo Stortingsgaten 2 Oslo Norway |
|
Registered owner |
T.A.C.K. Shipping S.A. Oslo Norway |
|
Renamed |
2017 Kathrine Kosan United Kingdom - Call sign: MAFV2 |
|
Last update |
14 September 2020 |
