| Zeebrugge 25 October 2008 |
|
Name |
NEWMARKET |
|
Type |
Liquefied Gas Tanker |
|
IMO-number |
9205574 |
|
Call sign |
C6QO8 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
6.560 t registered |
|
DWT |
Summer: 8.485 t |
|
NT |
1.968 t registered |
|
Length |
117,09 m overall |
|
Breadth |
19,60 m |
|
Moulded L x B x D |
109,00 x 19,60 x 9,75 m |
|
Registered L x B x D |
109,02 x 19,60 x 9,75 m |
|
Draught |
Summer: 7,584 m |
|
Bow to bridge |
94,63 m |
|
Air draft |
34,40 m |
|
Freeboard |
Summer: 2.204 mm |
|
Depth |
9,75 m |
|
Speed |
Service: 14,8 knots Trial: 17,1 knots |
|
Built |
1999 |
|
Keel laid |
10.06.1998 |
|
Launch date |
16.03.1999 |
|
Date of completion |
23.06.1999 |
|
First movement |
27.06.1999 |
|
Builder |
Higaki Shipbuilding Co Ltd. |
|
Yard number |
506 |
|
Hull type |
Single hull Double bottom |
|
Bulkheads watertight |
6 |
|
Main engine |
1x Mitsubishi - 2 stroke single acting 6 cylinders 450 x 1.350 mm diesel engine - 5.295 kW at 158,0 rpm Manufacturer: Akasaka Diesels Ltd. |
|
Number of screws |
1 |
|
Boiler |
1x Auxiliary vertical boiler - 6,9 bar Evaporation: 1,26 t/h Manufacturer: Miura Co. Ltd. |
|
Generators |
4x Diesel generatorsets - 2.362 kVA |
|
Cargo capacity |
6.527 m³ |
|
Tank capacities |
Ballast: 3.156 m³ Fresh water: 247,00 m³ Fuel oil: 847,00 m³ |
|
Lifting equipment |
1x Crane - SWL 4,0 t |
|
Crew |
18 |
|
Ship manager |
Maruta Industries Co. Ltd. |
|
Registered owner |
Geisel Compania Maritime S.A. 31ST ST., 3-80 |
