MOL Rainbow - IMO 9225782

Name

MOL RAINBOW

Previous name

2003-2003 Louis Delmas

Type

Cellular Containership

IMO-number

9225782

Call sign

C4ZW2

Flag

Cyprus

Previous flag

2003-2007 Bahamas

Port of registry

Limassol

GT

26.061 t
Suez: 27.017 t

DWT

Summer: 30.453 t

NT

10.209 t
Suez: 22.315 t

Number of 20ft containers

2.207

Container capacity 14t

1.725

Reefer point

350 reefer plugs

Length

195,60 m overall
183,13 m between perpendiculars

Breadth

30,20 m

Draught

Summer: 11,01 m

Freeboard

5.625 mm

Depth

16,60 m

Speed

21,5 knots

Built

2003

30.03.2003

Builder

China Shipbuilding Corporation
Kaohsiung Shipyard
Keelung
Taiwan

Yard number

777

Hull material

Steel

Hull type

Single hull

Watertight compartment

8

Number of cont. decks

1

Main engine

1x MAN B&W 8S70MC-C - 2 stroke 8 cylinder 700 x 2.800 mm engine - 24.847 kW / 33.764 hp at 91,0 rpm
Built: 2001
Builder: Hyundai Heavy Ind. Co., Ltd. - Engine & Mach Div., Ulsan - South Korea

Number of screws

1x Screw propeller solid at 91 rpm

Boilers

1x CHO OSAKA 47,00 m² - 7,8 bar
1x CHR OSAKA 625,00 m² - 12,0 bar

Electrical installation

Power Voltage: 440 V 50 Hz
Lighting Voltage: 220 V 50 Hz

Generators

4x MAN-B&W 6L28/32H main diesel generatorsets each 1.500 kVA - 1.200 kW - 1.732 hp

Emergency generators

1x Diesel generatorset 150 kVA - 120 kW - 179 hp

Bow thruster

1.100 kW

Cargo hatchways

9
Dimension:
1x 12,60 x 15,80 m
1x 12,60 x 25,60 m
7x 12,60 x 25,10 m

Fuel oil capacity

2495,8 m³

Cargo gear

3x Cranes - SWL 45 t each

Crew

21

Manager

CMA CGM Marseille
France

Managing owners

GSL London

Operator

Delmas

Owner

Global Ship Lease 5 Ltd.
Nicosia
Cyprus
