Westerschelde 05 November 2018 |
|
Name |
EVER GIVEN |
|
Type |
Cellular containership - Carriage of dangerous goods |
|
IMO-number |
9811000 |
|
Call sign |
H3RC |
|
Flag |
Republic of panama |
|
Port of registry |
Panama City |
|
GT |
217.612 t registered Suez: 220.940,23 t |
|
DWT |
199.500 t |
|
NT |
100.439 t registered Suez: 208.421,43 t |
|
Number of 20ft containers |
20.388 |
|
Length |
399,94 m overall 386,95 m between perpendiculars |
|
Breadth |
58,00 m moulded |
|
Draught |
Max: 16,00 m |
|
Freeboard |
10.226 mm |
|
Depth |
32,90 m moulded |
|
Speed |
Max: 23,1 knots |
|
Built |
2018 |
|
Keel laid |
25/12/2015 |
|
Launch date |
09/05/2018 |
|
Date of completion |
25/09/2018 |
|
Builder |
Imabari Shipbuilding Co., Ltd. |
|
Yard number |
S-1833 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Watertight bulkheads |
14 |
|
Main engine |
1x 6G70ME-C9.5 - 11 cylinder 950 x3.460 mm combustion engine 59.300 kW / 80.626 hp at 79,0 rpm Manufacturer: Mitsui Engr. & Shipbuilding Co. Ltd. |
|
Propellers |
1x Fixed propeller Manufacturer: Nakashima Propeller Co., Ltd. |
|
Boilers |
1x Fired auxiliary boiler 8,0 bar 1x Exhaust gas economizer - 13,5 bar 2x Exhaust gas economizer - 11,0 bar |
|
Generators |
4x HEW 80B-10 main combustion generatorsets each 4.600 kW Manufacturer: Taiyo Electric Co., Ltd. |
|
Number of holds |
11 |
|
Number of tanks |
Ballast: 47 Fuel oil: 9 Waste water: 3 Fresh water: 3 Chain: 2 Diesel oil: 2 Lubricating oil: 2 Sludge: 1 Sewage: 1 |
|
Tank capacities 100% |
Diesel oil: 1.431,87 m³ Freshwater: 512,72 m³ Fuel oil: 13.711,4 m³ Lube oil: 113,43 m³ Tank Ballast: 61.419,53 m³ |
|
Lifting equipment |
1x Monorail Crane - SWL 13,0 t Manufacturer: Oriental Prec & Eng'g Co. 1x Provision Crane port - SWL 4,0 t 1x Provision Crane starboard - SWL 4,0 t Manufacturer: Nantong Sekigahara Machinery Manufacturing Co., Ltd. |
|
Manager |
Bernhard Schulte Shipmanagement (Hong Kong) Limited Partnership |
|
Operator |
Evergreen |
|
Registered owner |
Luster Maritime/Higaki Sangyo |
|
Latest data adjustment |
09 September 2019 |
