Name |
MSC JENNY |
|
Previous names |
05/1995 - 05/2015 Alianca Europa |
|
Type |
Cellular containership |
|
IMO-number |
9000742 |
|
Call sign |
CQDA |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
Previous flags |
1995 - 2015 Brazil, Rio De Janeiro - Call sign: PPSV 2015 - 2015 Liberia, Monrovia - Call sign: D5IY9 |
|
GT |
28.397 t |
|
DWT |
Summer: 32.984 t |
|
NT |
10.894 t |
|
Number of 20ft containers |
2.161 |
|
Container capacity 14t |
1.850 |
|
Reefer points |
650 |
|
Length |
200,05 m overall 190,54 m between perpendiculars |
|
Breadth |
32,20 m |
|
Draught |
Max: 12,00 m |
|
Freeboard |
Summer: 6.820 mm Winter: 7.050 mm |
|
Depth |
18,82 m |
|
Speed |
Max: 18,5 knots |
|
Built |
1995 |
|
Launch date |
11/03/1994 |
|
Date of completion |
01/05/1995 |
|
Builder |
CCN - Companhia Comercio e Navegacao Estaleiro Maua S.A. Niteroi Brazil |
|
Yard number |
196 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight compartments |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x Sulzer-Dalian Marine Diesel Works 6RTA76 - 2 stroke single acting 6 cylinder 760 x 2.200 mm combustion engine 16.260 kW / 22.086 bhp at 98,0 rpm Builder: Dalian Marine Diesel Co., Ltd. - China |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
1x CHR 380,00 m² - 9,0 bar (Economiser) 1x CHO Aalborg 43,20 m² - 9,0 bar |
|
Shaft generator |
1x 3.250 kVA - 2.600 kW |
|
Generators |
1x Diesel generatorset 1.160 kVA - 928 kW - 1.427 hp 1x Diesel generatorset 1.615 kVA - 1.292 kW 1x Diesel generatorset 1.615 kVA - 1.292 kW - 1.997 hp |
|
Emergency generator |
1x Diesel generators 150 kW |
|
Bow thruster |
1x 1.180 kW |
|
Number of holds |
5 |
|
Total capacity of holds |
51.126,7 m³ |
|
Tank capacities |
Fuel: 3.881,7 m³ Ballast: 8.477 m³ |
|
Cargo gear |
2x Deck cranes - SWL 40,0 t each |
|
Crew size |
37 |
|
Commercial manager |
MSC Mediterranean Shipping Co SA, Geneva - Switzerland |
|
ISM manager |
MSC Shipmanagement Ltd. MSC House, 8, Spyrou Kyprianou Avenue Limassol Cyprus |
|
Registered owner |
One Star MSC Limited Care of MSC Mediterranean Shipping Co SA chemin Rieu, 12-14 1208 Geneva Switzerland |
|
Previous owners |
2000 Transferred Alianca Navigacao e Logistica Ltda Rio de Janeiro Brazil 2015 Wellington Marine Investment Ltd (MSC Shipmanagement Ltd Limassol as manager) Limassol, Cyprus,renamed " MSC JENNY " 2018 Transferred to One Star MSC Ltd (Same manager), Funchal Madeira |
|
Latest data adjustment |
15 January 2022 |
