Westerschelde 17 January 2020 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 17/01/20 | Westerschelde 12/01/19 | Westerschelde 12/01/19 | Westerschelde 15/10/18 | Westerschelde 14/03/18 | WS 20/08/19 |
|
Name |
CAP SAN ARTEMISSIO |
|
Type |
Cellular containership |
|
IMO-number |
9633939 |
|
Previous classification |
DNV GL |
|
Call sign |
3EQA4 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
Previous flags |
Germany Until: 2018 Republic of Singapore, Singapore City - Call sign: 9V2238 |
|
GT |
119.441 t registered |
|
DWT |
131.095 t |
|
NT |
55.522 t registered |
|
Number of 40ft containers |
9.814 |
|
Container capacity 14t |
7.569 |
|
Reefer capacity |
2.100 |
|
Length |
333,19 m overall 317,98 m between perpendiculars |
|
Breadth |
48,25 m extreme 48,20 m moulded |
|
Draught |
14,00 m |
|
Moulded L x B x D |
318,00 x 48,20 x 19,57 m |
|
Registered L x B x D |
318,45 x 48,20 x 22,46 m |
|
Freeboard |
5.082 mm |
|
Depth |
19,57 m moulded |
|
Speed |
Max: 22,8 knots |
|
Built |
2014 |
|
Keel laid |
01/10/2013 |
|
Launch date |
13/12/2013 |
|
Date of completion |
01/05/2014 |
|
Builder |
Hyundai Heavy Ind. Co., Ltd. Ulsan South Korea |
|
Yard number |
2527 |
|
Hull material |
Steel |
|
Hull type |
Single hull double bottom |
|
Watertight bulkheads |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x HHI/MAN B&W 7S90ME-C9.2 - 2 stroke 7 cylinder 900 x 3.260 mm combustion engine 40.670 kW / 55.296 hp at 84,0 rpm Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 870 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired Aalborg CHB-5000 - 9,0 bar Evaporation: 4,50 t/h 1x Auxiliary boiler, exhaust gas heated Aalborg XS-2V - 9,0 bar Evaporation: 4,00 t/h Manufacturer: Alfa Laval Qingdao Ltd. |
|
Generators |
5x Hyundai/HimSen 9H32/40 main diesel generatorsets each 4.320 kW |
|
Emergency generator |
1x AD180TIS diesel generatorset |
|
Bow thruster |
2.500 kW, forward 1.900 kW, aft |
|
Number of cargo holds |
8 |
|
Number of tanks |
Ballast: 26 Fuel oil: 12 Lubricating oil: 7 Waste water: 3 Diesel oil: 3 Fresh water: 3 Chain: 2 Sludge: 2 |
|
Tank capacities |
Diesel Oil: 1.522,1 m³ Freshwater: 598,4 m³ Fuel Oil: .8.773,6 m³ Lube Oil: 453,8 m³ Tank Ballast: 31.327,8 m³ |
|
Anchor equipment |
Length: 770,00 m Diameter: 117 mm |
|
Cargo gear |
Gearless |
|
Crew size |
30 |
|
ISM & commercial manager |
Synergy Maritime Private Limited4th Floor, AKDR Tower, 3/381, Rajiv Gandhi Salai (OMR), Mettukuppam Chennai, 600097 India |
|
Previous manager |
2014 - 2018 ENESEL Limited, Limassol - Cyprus |
|
Operator |
Hamburg Süd |
|
Registered |
Green Spanker Shipping S.A. Kyowa Kisen Co., Ltd. Care of Kyowa Kisen Co Ltd. 829-1, Kinoura, Hakata-cho, Imabari-shi, Ehime-ken, 794-2305 Japan |
|
Previous owners |
2014 - 2018 Cap San Artemissio Pte Ltd. |
|
Latest data adjustment |
06 February 2022 |
