Polar Ecuador 01

Antwerpen 17 September 2018



Name

POLAR ECUADOR

Type

Cellular containership

IMO-number

9786774

Call sign

9V8896

Flag

Republic of Singapore

Port of registry

Singapore City

Previous flags

11/2017 - 03/2018 Liberia, Monrovia - Call sign: D5OZ2

GT

43.628 t registered

Suez: 45.663,24 t

DWT

52.056 t

NT

17.495 t registered

Panama: 36.023 t

Suez: 40.184,6 t

Number of 20ft containers

3.800

Length

230,00 m

Breadth

37,30 m

Draught

12,50 m

Freeboard

7.139 mm

Depth

19,60 m

Speed

Service: 18,0 knots

Max: 21,1 knots

Built

2017

Keel laid

17/12/2015

Launch date

17/07/2017

Date of completion

22/11/2017

Builder

Jiangsu New Yangzi Shipbuilding Co., Ltd.
Jingjiang
China

Yard number

YZJ2015-1202

Hull material

Ordinary strength steel

High strength steel

Watertight bulkheads

8

Main engine

1x Hyundai-MAN B&W 6S70ME-C8.5 - 2 stroke 6 cylinder 700 x 2.800 mm combustion engine 19.620 kW / 22.674 bhp at 91,0 rpm

Manufacturer: HHI Engine & Machinery Div.

Propellers

1x Fixed pitch propeller

Boilers

1x Composite boiler - 9,0 bar

1x Unfired exhaust gas boiler - 9,0 bar

Manufacturer: Saacke Qingdao Marine Boiler Co., Ltd.

Generators

3x Daihatsu 8DE33 main diesel generatorsets each 4.520 kW

1x Daihatsu 6DE33 main diesel generatorset 3.080 kW

Manufacturer: HHI Electro Electric System

Number of holds

5

Cargo hold capacity

77.177,05 m³

Number of tanks

Ballast: 26

Fuel oil: 14

Lubricating oil: 8

Waste water: 5

Sludge: 5

Diesel oil: 4

Fresh water: 4

Chain: 2

Sewage: 1

Tank capacities 100%

Diesel oil: 434,68 m³

Freshwater: 469,12 m³

Fuel oil: 4.829,92 m³

Lube oil: 297,46 m³

Tank Ballast: 20.288,23 m³

Lifting equipment

1x Engine room overhead crane - SWL 6,3 t
Manufacture: Jiangyin Jianghai Mechnical Manufacture Co.,Ltd.

1x Hose davit/Suez boat davit - SWL 4,0 t

Manufacture: Taizhou Kaixin Shipping Machine Co., Ltd.

1x Monorail provision crane - SWL 6,5 t

Manufacture: Oriental Prec & Eng'g Co.

Cargo gear

2x Deck cranes - SWL 44,0 t each

Manufacture: TTS Bohai Machinery Dalian Co Ltd.

Manager

Hamburg-Süd/Columbus Shipmanagement GmbH
Willy-Brandt-Str. 59-61
20457 Hamburg
Germany

Operator

Hamburg Süd

Registered owner

A P Møller Singapore Pte Ltd.

Latest data adjustment

19 October 2018
