CMA CGM White Shark IMO 9317975 06

Westerschelde 11 December 2019



CMA CGM White Shark IMO 9317975 07   CMA CGM White Shark 01   CMA CGM White Shark 02   CMA CGM White Shark IMO 9317975 03   CMA CGM White Shark IMO 9317975 05   CMA CGM White Shark IMO 9317975 04
Westerschelde 11/12/19 Westerschelde 20/02/18 Westerschelde 20/02/18 Westerschelde 23/03/20   Westerschelde 04/02/20   Westerschelde 04/02/20



Name

CMA CGM WHITE SHARK

Type

Cellular containership - Panamax

IMO-number

9317975

Call sign

9HA5021

Flag

Malta

Port of registry

Valletta

Previous flags

United Kingdom, London- Call sign: MPXV7 until 2019

GT

54.309 t

Suez: 55.817 t

DWT

Summer: 65.892,5 t

NT

34.011 t

Suez: 48.768 t

Number of 20ft containers

In hold: 2.203

On deck: 2.892

Total: 5.095

Container capacity 14t

3.306

Reefer points

330

Length

294,12 m overall

278,73 m between perpendiculars

Breadth

32,20 m

Draught

Summer: 13,52 m

Freeboard

3.867 mm

Depth

21,80 m

Speed

22,8 knots

Built

2007

Date of completion

23/04/2007

Builder

Hyundai Heavy Industries Co., Ltd.

Ulsan

South Korea

Yard number

1711

Hull material

Steel

Watertight compartments

9

Continuous decks

1

Main engine

1x Hyundai/MAN-B&W 10K98MC-C6-TI - 2 stroke single acting 10 cylinder 980 x 2.400 mm combustion engine 57.075 kW / 77.599 hp at 104,0 rpm

Built: 2003

Manufacturer: Hyundai Heavy Ind. Co., Ltd. - Engine & Mach. Div. - South Korea

Propellers

1x Fixed pitch propeller - aft at 104,0 rpm

Boilers

1x CHR Aalborg 392,00 m² - 7,0 bar

1x CHO Aalborg 40,14 m² - 7,0 bar

Electric installations

Power voltage: 450 V

Lighting voltage: 220 V

Frequency: 60 Hz

Generators

3x Main diesel generatorsets each 3.000 kVA - 2.400 kW - 3.465 hp 450/220 Volt 60 Hz

Emergency generator

1x Diesel generatorset 250 kVA - 200 kW - 345 hp

Bow thruster

1x Tunnel thruster 1.800 kW / 2.447 bhp, forward

Number of holds

6

Tank capacities

Fuel oil: 8.881,5 m³

Cargo gear

Gearless

Crew size

19

Commerical manager

CMA CGM SA The French Line

4, quai d'Arenc

13002 Marseille

France

ISM manager

CMA CGM International Shipping

14-01, The Metropolis (Tower 1)

9, North Buona Vista Drive

Singapore 138588

Republic of Singapore

Registered owner

SNC Fenice Bail 2

Care of CMA CGM SA (The French Line)

4, quai d'Arenc

13002 Marseille

France

Latest data adjustment

12 May 2022
