Name |
CMA CGM AFRICA THREE |
|
Type |
Cellular containership |
|
IMO-number |
9451939 |
|
Call sign |
C6YS8 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
40.827 t |
|
DWT |
Summer: 51.604 t |
|
NT |
24.146 t |
|
Number of 20ft containers |
3.718 |
|
Container capacity 14t |
2.966 |
|
Reefer capacity |
595 |
|
Length |
228,00 m overall 217,30 m between perpendiculars |
|
Breadth |
37,30 m |
|
Draught |
12,45 m |
|
Freeboard |
3.286 mm |
|
Depth |
19,34 m |
|
Speed |
21,6 knots |
|
Built |
2010 |
|
Date of completion |
30/09/2010 |
|
Builder |
HHIC-PHIL, Inc. (Hanjin Heavy Industries & Construction Co., Ltd., Subic Bay) Philippines |
|
Yard number |
P0018 |
|
Hull material |
Steel |
|
Watertight compartments |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 7RT-FLEX82C - 2 stroke single acting 7 cylinder 820 x 2.646 mm combustion engine 31.640 kW / 43.018 hp at 102,0 rpm Built: 23/12/2008 Builder: Hyundai Heavy Ind. Co., Ltd. - Engine & Mach. Div., Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 102 rpm |
|
Boilers |
1x CHM Aalborg-Qingdao 362,00 m² - 10,0 bar |
|
Generators |
4x Himsen 9H25/33 main diesel generatorsets each 2.625 kVA - 2.100 kW - 3.003 hp |
|
Emergency generator |
1x Diesel generatorset 188 kVA - 150 kW - 255 hp |
|
Number of holds |
5 |
|
Total capacity of holds |
79.027,3 m³ |
|
Tank capacities |
Fuel oil: 6.948,99 m³ |
|
Cargo gear |
3x Mac Gregor hydraulic cranes - SWL 45 t each 1x Mac Gregor hydraulic crane - SWL 30 t |
|
Commercial manager |
CMA CGM SA The French Line 4, quai d'Arenc 13002 Marseille France |
|
ISM manager |
CMA CGM International Shipping 14-01, The Metropolis (Tower 1) 9, North Buona Vista Drive Singapore 138588 Republic of Singapore |
|
Registered owner |
Beaufort Sea Shipping Corporation Care of CMA CGM SA (The French Line) 4, Quai D’Arence 13002 Marseille France |
|
Latest data adjustment |
08 April 2022 |
