Westerschelde 07 July 2016 |
 |
 |
|
| Westerschelde 17/03/16 | Westerschelde 27/04/19 | |
|
Name |
MSC ARBATAX |
|
Previous names |
Launch as: 2013 Johanna Schulte |
|
Type |
Cellular containership - Post-Panamax |
|
IMO-number |
9605231 |
|
Call sign |
VRMO6 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Hong |
|
GT |
94.402 t |
|
DWT |
Summer: 111.841 t |
|
NT |
52.968 t |
|
Number of 20ft containers |
9.403 |
|
Container capacity 14t |
7.100 |
|
Reefer capacity |
1.000 |
|
Length |
299,88 m overall 283,25 m between perpendiculars |
|
Breadth |
48,34 m extreme 48,20 m moulded |
|
Draught |
14,50 m |
|
Depth |
24,80 m |
|
Speed |
Max.: 22,2 knots |
|
Built |
2013 |
|
Keel laid |
10/09/2012 |
|
Launch date |
11/04/2013 |
|
Date of completion |
14/10/2013 |
|
Builder |
Shanghai Jiangnan Changxing Heavy Industry Co., Ltd. China |
|
Yard number |
H1066A |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W 9S90ME-C9.2 - 2 stroke single acting 9 cylinder 900 x 3.200 mm combustion engine 52.290 kW / 71.093 hp at 84,0 rpm Builder: MAN Diesel & Turbo SE, Augsburg - Germany |
|
Propellers |
1x Fixed pitch propeller - aft at 84,0 rpm |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated (Exhaust gas economiser) 1x Auxiliary boiler, oil/gas fired (Oil fired boiler) |
|
Generators |
4x Daihatsu 8DC-32e - 4 stroke 8 cylinder 320 x 400 mm diesel engine each 3.500 kW coupled with 4 generatorsets each 3.320 kW |
|
Emergency generator |
1x MAN D2866 LE 203 diesel generatorset |
|
Bow thruster |
1x Tunnel thruster 3.000 kW / 4.079 bhp, forward |
|
Anchor equipment |
Length: 770,00 m Diameter: 111 mm |
|
Cargo gear |
Gearless |
|
Crew size |
23 |
|
Manager |
Bernhard Schulte Shipmanagement (Hong Kong) Limited Partnership 2602, K Wah Centre 191 Java Road North Point Hong Kong |
|
Operator |
MSC - Mediterranean Shipping Company |
|
Registered owner |
Draycort Park Shipping Co. Pte. Ltd. |
|
Renamed |
11/2020 Johanna Schulte Hong Kong - Call sign: VRMO6 Owner: Draycort Park Shipping Co. Pte. Ltd. Manager: Bernhard Schulte Shipmanagement (Hong Kong) Limited Partnership 11/2023 MSC Dakar X Portugal, Madeira - Call sign: CQ2075 Owner: Johanna Oceanway Limited Manager: Bernhard Schulte Shipmanagement (Hong Kong) Limited Partnership |
|
Latest data adjustment |
01 April 2024 |
