Delmas Kissama - IMO 8002585

Name

DELMAS KISSAMA

Previous names

1982-1987 Suzanne Delmas
1987-1990 Ville De Marseille
1990-1997 Suzanne Delmas
1997-1998 Marfret Caraibes
1998-1999 Suzanne
1999-2003 Suzanne Delmas
2003-2007 MOL Horizon
2007 Delmas Kissama

Type

Cellular containership

IMO-number

8002585

Call sign

C6PE5

Flag

Bahamas

Previous flag

1998 - France

Port of registry

Nassau

GT

20.024 t
Suez: 21.357 t

DWT

Summer: 26.287 t

NT

10.022 t
Suez: 16.267 t

Number of 20ft containers

1.104

Container capacity 14TH

1.036

Reefer point

104 reefer plugs - 440 V / 60 Hz

Length

176,96 m overall
164,41 m between perpendiculars

Breadth

28,05 m overall

Draught

Summer: 11,42 m

Freeboard

4.680 mm

Depth

16,10 m

Speed

17,6 knots

Built

1982

20.03.1982

23.06.1982

Builder

Chantiers de l'Atlantique
Saint Nazaire
France

Yard number

U27

Hull material

Steel

Hull type

Single hull

Watertight compartments

8

Continuous decks

1

Main engine

1x Pielstick 10PC4 V 570 - 4 stroke 10 cylinder 570 x 620 mm diesel engine - 8.832 kW / 12.000 hp at 386 rpm
Built: 1981
Builder: Alstom Marine Paris - France

Propelling system

1x Screw propeller solid at 77 rpm

Boilers

1x CHM 19,00 m² - 7,6 bar
1x CHR 135,00 m² - 7,5 bar

Electrical installation

Power voltage: 440 V
Lighting voltage : 220 V

Shaft generator

1.080 kW

Diesel generators

2x Main diesel generatorsets each 1.690 kVA - 1.352 kW - 4.440 hp

Cargo holds

4

Hatchways

13
9x 12,90 x 10,80 m
2x 12,90 x 8,00 m
2x 13,10 x 10,80 m

Tank capacities

Bunker: 1.300 t
Fuel oil: 2.050 m³

Cargo gear

2x Cranes - SWL 5,0 t each
4x Cranes - SWL 40,0 t each

Crew

20

Manager

CMA CGM
Marseille
France

Operator

Delmas

Owner

Delmas
Le Havre
France
